1.Double-head Cutting Saw for aluminum & pvc profiles

2.Imported carbide saw blade for accurate processing and high efficiency.

Features: 1. The linear guiding pair ensures steady processing accuracy

2. Saw blade rotates smoothly due to high accuracy main spindle

3. Uniform speed feeding and smooth motion are due to hydraulic damping cylinder

4. It has feature of easy operation, reliable performance, advanced technique and convenient maintenance, etc

5. Right cutting head moving is driven by motor

6. Imported carbide saw blade is of accurate processing and high efficiency

7. The Improved Safety cover is more reliable and safety for operation.

8. The digital measurement display is optional

Technical parameter:

Power supply 380V 50Hz

Air pressure 0.5-0.8Mpa

Cutting motor power 2x1.5Kw

Rotary Speed 2800r/min

Air consumption 60L/m

Blade specification 450X30X4.4 Z=120

Cutting length max 3700mm min 580mm (45°) Max 3700mm min 400mm(90°, 135°)

Cutting width max 120mm

Cutting height max 200mm

Cutting angle 90°, 45°,135°(optional)

Cutting angle allowance ±5

Cutting speed 0-0.3m/min

Cutting profile surface planeness <=0.1mm

Cutting profile surface roughness Ra 12.5

Overall dimension 4500X1170X1400mm

Weight 1500kg

Remarks:

A.Terms: Freight On Board (FOB Qingdao)
B. Delivery Time: During 15 Days After We Receive Your First Payment.
C. Payment: Telex Transfer (T/T), 30% be Paid as deposit, and the rest 70% is paid before delivery the
machine.

D. Guarantee period:  1 year from the date of customer receiving the machines.

                                    24hour technical support by email or calling.

                                    User-friendly english manual for machine using and maintaining.
