Glas Washing and Drying Machine Vertical Model

Glas Washing and Drying Machine Vertical Model thumbnail-1
Glas Washing and Drying Machine Vertical Model thumbnail-2
Glas Washing and Drying Machine Vertical Model thumbnail-3
Glas Washing and Drying Machine Vertical Model thumbnail-4
Glas Washing and Drying Machine Vertical Model thumbnail-5
Glas Washing and Drying Machine Vertical Model thumbnail-6
Glas Washing and Drying Machine Vertical Model photo-1
Glas Washing and Drying Machine Vertical Model photo-2
Glas Washing and Drying Machine Vertical Model photo-3
Glas Washing and Drying Machine Vertical Model photo-4
Glas Washing and Drying Machine Vertical Model photo-5
Glas Washing and Drying Machine Vertical Model photo-6
US$ 5,000 - 13,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Sunny
Place of Origin:
Shandong, China
Model Number:
LBW series
Contact Supplier Request Quote Chat Now
Nanjing Vacuum Bagging Film Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Sunny
Place of Origin Shandong, China
Model Number LBW series
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 24month
Weight 2000KG
Dimension(L*W*H) 9000x1800x3500mm
Production Capacity 300-500 Pc
Condition New
Voltage According to customer request
Power(W) 12kw
Machine Type Glass Washing and Drying Machine

Glas washing and drying machine vertical model

Contact person: Ms. Lucy  Tel or whatsapp: 0086 151 6904 2082

Glas washing and drying machine vertical model



We have two tyes, Vertical mould and Horizontal mould. It include three parts :Glass input part, Glass wash and dry part, Glass output part.



Introduction:

* PLC control system with touch screen operation interface

* Glass wash and dry part is with stainless steel, and soft brush can wash LOW-E glass
* Apply water-proof shaft and bearing in the drying section
* Perfect Low-E glass washing performance
* Adopt interval working design for saving energy
* Six pieces of soft brushes



We have some sizes moulds for your reference.

Mould wash max.glass size wash Min.glass size Brush
LBW2500 2500x3300mm 380x450mm 6 pieces of Soft brush
LBW2200 2200x33000mm 380x450mm 6 pieces of Soft brush
LBW2000 2000x3000mm 380x450mm 6 pieces of Soft brush
LBW1800 1800x2440mm 380x450mm 6 pieces of Soft brush
LBW1600 1600x2000mm 380x450mm 6 pieces of Soft brush




Glas washing and drying machine vertical model

Glas washing and drying machine vertical model Glas washing and drying machine vertical modelGlas washing and drying machine vertical model





Warmly welcome! Please feel free to tell me if you have any questions and inquiry about machines, thanks.

Contact person:Ms. Lucy Lu

TEL:+86 15169042082



Horizontal glass washing machine picture for your reference

Glas washing and drying machine vertical model
