Insulating glass machine 1600x2000mm vertical insulating glass production line machine
It include Seven Parts, Glass Transporter part, Glass washing and drying part, Glass inspecting part, Aluminum spacer bar install part, Flat press part, Insulating Glass transporter, Tilting table.
For Double Glazing Glass Machine, we have two kinds, Vertical Style and Horizontal Style.
And Vertical Style, we have Automatic Flat press style and Semiautomatic Roller Press style.
We can make this machine according to customer producing Double glazing glass size.
Now I list some styles for reference.
| Model | Max. Glass size | Min.Glass size | Glass thickness | Brush | Max.washing | Power | weight | size of line | |
|
LBZ2500
|
2500x3000mm | 300x450mm | 3-50mm | 3Pairs | 12m/min | 25kw | 9000kg | 22000x2000x3380mm | |
|
LBZ2000
|
2000x2440mm | 300x450mm | 3-50mm | 3Pairs | 12m/min | 20kw | 6000kg | 14000x1680x2800mm | |
|
LBZ1800
|
1800x2440mm | 300x450mm | 3-50mm | 3Pairs | 10m/min | 18kw | 5000kg | 14000x1680x2600mm | |
|
LBZ1600
|
1600x2000mm | 300x450mm | 3-25mm | 2Pairs | 10m/min | 13.59kw | 4000kg | 12000X1250X1600mm |
Warmly welcome to contact me if you have any request and questions.
Flat Press Style Insulating glass productiong line
Roller Press style insulating glass Production Line
Contact person: Lucy
wechat : LucyLi2010
Mobilephone:+86 15169042082
Please kindly contact me if you have any questions, thank you! :)
Others accessory machines for insulating glass
Insulating glass line with sealing robotic
Aluminum spacer bending machine
Butyl extruder machine for insulating glass line
Two component silicon extruder machine for Insulating glass line
Automatic Desiccant filling machine for insulating glass line
More machines specification, warmly welcome to inquiry me, thank you.
Contact person: Lucy
wechat : LucyLi2010
Mobilephone:0086 15169042082
Please kindly contact me if you have any questions, thank you!
