Two Component Polyurethane Sealant Dispensing Machine

Two Component Polyurethane Sealant Dispensing Machine thumbnail-1
Two Component Polyurethane Sealant Dispensing Machine photo-1
US$ 9,000 - 9,700 MOQ: 11 Sets
Key Specifications
Get Latest Price
Brand Name:
WEILI
Place of Origin:
Shandong, China
Certification:
CE
Contact Supplier Request Quote Chat Now
Qingdao Yuntai Industry Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name WEILI
Place of Origin Shandong, China
Certification CE
Warranty 1 Year
Weight 600kg
Dimension(L*W*H) 800*800*2000mm
Production Capacity 20sets/month
Condition New
Power(W) 11KW
Machine Type Glass Coating Machine

                           ST06 Two component  sealant spreading machine



1Using adjustable supercharging ratio of synchronous linkage mechanism





2 This machine adopt the advanced technology at home and abroad, including key components (main motor, assistant motor, purging pressure valve, mixed core and glue gun) adopt overseas brand KOREA HANSHINproducts and ensure reliable operation.



3 This system include air motor, main ingredient pump, proportion pump, platen, feed pump, glue gun, puddler, proportion testing station and other devices.Using adjustable supercharging ratio of synchronous linkage mechanism, adapt to material ratio of different material(6:1-14:1), and have special ratio inspection station.



4 Using adjustable supercharging ratio of synchronous linkage mechanism, After adjusting air pressure the first time, we will not do anything, then, supplying glue, proportion, mixing and spraying. Every time only need to gently pull the gun trigger, can make the whole system start. Sensitive high pressure valve can make operation and use more secure.



5 All parts connected with fluid water adopt high quality stainless steal, seal ring adopt import excellent Teflon material and seal is durable and reliable.



Main technical parameter:



Mixing proportion

6:1-14:1 changeable

Basic material barrel

55 gallon (220L)

Curing agent barrel

5 gallon (20L)



Max air consumption

0.8CBM/min

Pressure ratio between air and glue

50:1

Max squeeze pressure

29Mpa



Gas supplying pressure

0.5~0.8Mpa

Dimension

1100*950*1630mm

Total weight

600kg



Fluid max working pressure

34.5Mpa



Max output

10L/min







Company Information







two component polyurethane sealant dispensing machine

two component polyurethane sealant dispensing machine



Product Description

 two component polyurethane sealant dispensing machine

 two component polyurethane sealant dispensing machine



Packaging & Shipping
