General Information:
SXGK-H is designed to test the mechanical dynamic characteristics various voltage degree vacuum, SF6, with oil and etc high voltage and low voltage circuit breakers.
Features:
√ 7 inch large color LCD, can read clearly even in direct sunlight.
√ Friendly English interface, touching key, easy to operate.
√ Build-in printer.
√ Integrated power supply, suitable for on-site test. DC20-265V adjustable power source, current 15A. The active voltage value of open/close coil can be set arbitrarily, the low voltage action of circuit breaker is also can be tested.
√ Universal type velocity sensor, easy to install.
√ All the data and graph can be available only by one time switching.
√ To be suitable for all kinds of GIS, SF6/vacuum/oil switchgears.
√ 6000 groups data storage (memory card is extendable). Built-in clock to save the test date and time.
√ USB port, to save the data to the U disk.
√ 12 channels metal contactors, three channels closing resistance measurement.
√ Built-in anti interference circuit, suitable for 500kV substation reliable testing.
Specifications:
√ Time test:12 channels
Open(Close)time
Open(Close)same phase no- synchronism
Open(Close)phase to phase no-synchronism
Close(Open)bounce time(bounce numbers)
Test range:0.1ms~999.99ms
Resolution: 0.01ms
√ Velocity test:Open(Close)velocity
Pointed periods of time(travel period or angle period)average speed
Open(Close)max.velocity.
Range: 1mm Sensor:0.01~25.00m/s,
0.1mm sensor: 0.001~2.50m/s
0.5°angle sensor: 1cycle/ 0.5°
√ Travel test:Moving contactor travel
Contactor travel (open distance)
Overshoot travel or bounce travel (amplitude)
Sensor:50mm,Resolution:0.1mm
Sensor:300mm(option),Resolution: 0.1mm
360line sensor:360,resolution:0.5
300mm/500mm/universal sensor are optional.
√ Current: Max. current output 15A
√ AC source:AC 220V ± 10%;50Hz ± 2%
√ DC source:Output voltage:2~265V continuous adjustment,output current:≤ 15A(short time)
√ Control unit oversize:380×280×140mm
√ Working temperature:-10ºC~+50ºC
√ RH:≤90%
Warranty: One year quality guarantee after shipment.
Please kindly contact with us for further information.
