10.5kw-99.4kw Geothermal Heat Pump Water To Water Heat Pump For Heating, Cooling
US$ 100 - 700
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Mango
Place of Origin:
China
Model Number:
MG-03SFXLRS/380
Payment & Shipping
Payment Methods:
Port of Shipment:
Huangpu port
Delivery Detail:
1 days
Related Products
-
3.5kw~10.5kw Household SPA Pool Heat PumpUS$ 100 - 500MOQ: 1 Piece -
3.8kw~10kw Heating Capcacity Household Air to Water Heat Pump(heating Mode, Monoblock Type)US$ 1 - 500MOQ: 1 Piece
-
Low Temperature Heat Pump Evi Air Source Floor Heaint and CoolingUS$ 1000 - 1500MOQ: 1 Piece
-
High Temperature Air Source Heat Pump 70~75℃ Hot Water With CE, TUVUS$ 1000 - 3400MOQ: 1 Piece
-
Hot Sale! EVI Air Source Heat Pump for Heating and Cooling Work at Cold AreasUS$ 1000 - 1300MOQ: 1 Piece
Brand Name
Mango
Place of Origin
China
Model Number
MG-03SFXLRS/380
| Item | MG-03SFXLRS | MG-03SFXLRS/380 | MG-05SFXLRS | MG-06SFXLRS | MG-10SFXLRS | MG-12SFXLRS | MG-15SFXLRS | MG-20SFXLRS | MG-25SFXLRS | |
| Heating capicity (W15/W55) | Kw | 10.5 | 11.8 | 21.3 | 25.2 | 42.6 | 50.4 | 56.7 | 74.8 | 99.4 |
| Heating input power | Kw | 2.6 | 2.6 | 4.4 | 5.2 | 8.8 | 10.6 | 12.5 | 16.8 | 21.5 |
| COP | 4.04 | 4.54 | 4.84 | 4.85 | 4.84 | 4.75 | 4.54 | 4.45 | 4.62 | |
| Cooling capicity (W12/W7) | Kw | 6.8 | 7.8 | 14 | 16.5 | 28 | 33 | 37.1 | 49.4 | 67 |
| Cooling input power | Kw | 2.2 | 2.5 | 4.2 | 4.8 | 8.4 | 10 | 12 | 16 | 20.5 |
| EER | 3.09 | 3.12 | 3.33 | 3.44 | 3.33 | 3.30 | 3.09 | 3.09 | 3.27 | |
| Current | A | 11 | 5.9 | 8 | 10.8 | 16 | 19 | 24 | 35 | 40 |
| Voltage | V/Hz | 220V-50Hz/1Ph | 380V-50Hz/3Ph | |||||||
| Rated/Max water temp | 55 --60°C | |||||||||
| Uusing side water flow | m3/H | 2 | 2.5 | 4.3 | 4.8 | 8.5 | 9.8 | 12.3 | 16.0 | 20.0 |
| Sourse side water flow | m3/H | 3.0 | 3.4 | 5.8 | 6.7 | 11.5 | 13.0 | 15.5 | 21.2 | 27.0 |
| Water pressure drop | kPa | 40 | 40 | 50 | 50 | 60 | 65 | 68 | 70 | 75 |
| Refrigeration | R417A/R407C/R410A | |||||||||
| Control mode | Microcomputer central processor (wire controller) | |||||||||
| Compressor | Type | Scroll | Scroll | Scroll | Scroll | Scroll | Scroll | Scroll | Scroll | Scroll |
| Qty | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 | |
| Brand | Copeland/Hitachi | |||||||||
| Heat Exchanger | Double-pipe heat exchanger | Shell and tube heat exchanger | ||||||||
| Throttling device | Emerson Thermal expansion valve | |||||||||
| Evaporator | Plate heat exchanger | |||||||||
| Water pipe diameter | DN25 | DN25 | DN25 | DN32 | DN32 | DN32 | DN50 | DN50 | DN65 | |
| Unit | dB(A) | ≦50 | ≦50 | ≦50 | ≦50 | ≦60 | ≦60 | ≦64 | ≦66 | ≦66 |
| mm | 710*520*1000 | 710*520*1000 | 710*520*1000 | 710*520*1000 | 1280*830*800 | 1280*830*800 | 1320*840*1130 | 1750*1120*1160 | 2000*1120*1160 | |
| Kg | 95 | 95 | 150 | 160 | 300 | 320 | 340 | 650 | 680 | |
