SLIDING AUTOMATIC DOOR DSL-200/200L

Name: SLIDING AUTOMATIC DOOR DSL-200/200L
Brand: YOMO
Availability: InStock

FOB Price

US$ 100 - 1000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

DSL -200/200L

TECHNICAL DATA

Door configuration： single leaf ,double leaf Door leaf weight limit：1×150kgs,2×120kgs Clean open width：600-1800mm, 1000-3000mm Power supply： AC 220V±10%,50/60HZ 2A AC 110V±10%,50/60HZ 2A Power consumption：65W Opening speed：200-500mm/s( adjustable) Closing speed：200-500mm/s( adjustable) Hold-open time：0-9S Manual force：<30N,<40N Environment temperature： -20°C~+50°C

MAIN FUNCTION

Outstanding Performance Themicrocomputercontrollerhasselflearningfunction;thedrivedeviceworkssmoothly, i t’ssafeandreliable;thecomprehensivefunctionscansatisfytheindividualneeds. European DesignStructure Motor,controller and belt pulley are hanging in the top of guide rail,gives large space for big hangers to drive smoothly,softnoise. Multi-functionalSwitch Manager can realize five functions conveniently on the automatic door:lock ,keep open,one way,half open,automaticoperation. SecurityRequirement The safety beam photocell will keep the door to offer the security for passer-by.In an emergency,press the abrupt stop switch,the door will stop immediately,security is fullyguaranteed. Fire SafetyRequirement The door will open automatically when fire happens,it helps to win more time for escapes .
