1. The brief introductions of KHYD110 rock drilling rig
l The machine can be fitted with drill stand, and can be drilled horizontally or upward in any direction.
l In order to prolong the service life of the drill bit and improve the working conditions of the operator, wet drilled water can be used to discharge the powder and screw blade drills can also be used for dry draining.
l In the operation of drilling rig, we only need to operate the handwheel, and the drilling rig can advance itself and return quickly.
2. The Specifications of KHYD110
Model |
Unit |
KHYD110 |
Rated output power of motor |
kw |
5.5 |
Rated voltage of motor |
v |
380/660 |
Rated frequency of motor |
hz |
50 |
Rated current of motor |
a |
11.6 |
Motor speed |
r/min |
1440 |
Motor phase number |
three phase communication |
|
Rated working mode |
continuity |
|
Drilling speed |
mm/min |
280 |
Speed of return |
m/min |
|
Borehole diameter |
mm |
42-80（rock） |
Hardness range |
protodikonov`s scale of hardness |
f |
Maximum drilling depth |
m |
20（rock） |
Weight of drilling rig (excluding runways, drill pipes, drills) |
kg |
110 |
Dimension (length * width * height) |
mm |
950*460*430 |
