P230 Handheld Particle Counter
The P230 remote particle counter measures 0.3 µm and 0.5 µm with a flow rate of 0.1 CFM (2.83 LPM). Integration is easy into a real-time monitoring or building management system via Modbus™ RTU or Modbus™ ASCII. The P230 is the smallest remote particle counter in the market and has easy mounting options. The P230 complies with ISO 21501-4 and includes a 2 year limited warranty.
P230 Remote Particle Counter Features & Benefits
• Measures 0.3 µm and 0.5 µm
• 0.1 CFM (2.83 LPM) flow rate
• Measures 2 channels of simultaneous data
• Long life laser diode
• Modbus™ RTU or Modbus™ ASCII outputs
• Concentration limit of 2,000,000 per ft³
• Complies with ISO 21501-4 and JIS B9921 standards
• Lightweight stainless steel enclosure
• Easy to clean and wipe down
• 2 year limited warranty
P230 Remote Particle Counter Specifications
| Channel Sizes |
0.3 µm and 0.5 µm |
| Counting Efficiency |
50% at 0.3 µm; 100% for particles > 0.45 µm (per JIS) |
| Concentration Limits |
2,000,000 particles / ft3 at 5% coincidence loss |
| Light Source |
Long life laser diode |
| Zero Count Level |
|
| Flow Rate |
0.1 CFM (2.83 LPM) |
| Flow Control |
Critical orifice |
| Vacuum Requirements |
External vacuum >15" (38.1 cm) of Hg |
| Calibration |
NIST traceable |
| Sample Probe/Tubing |
Isokinetic sampling probe |
| Communication Interface |
Modbus™ RTU or ASCII outputs (specified upon order) |
| Power |
9-30 VDC |
| Dimensions (L x W x H) |
1.8" x 3.7" x 1.5" (4.5 cm x 9.3 cm x 3.8 cm) does not include probes |
| Weight |
0.62 lb (0.28 kg) |
| Standards |
ISO 21501-4 and JIS B9921 |
| Warranty |
2 year limited warranty |
| Operating Conditions |
5 to 35°C, 20% to 95%RH non-condensing |
| Storage Conditions |
-20 to 50°C, Up to 98%RH non-condensing |
| Optional Accessories |
Isokinetic sampling probe, purge filter, data cable, vacuum and sample tubing |
