Help CenterXY-180 Hydraulic Core Drilling Rig Core Drilling Rig for Hard Rock
Related Products
-
XY-200 Hydraulic Core Drilling Rig Geophysical ExplorationUS$ 4200 - 4700MOQ: 1 Set -
XY-3 Hydraulic Core Drilling Rig Core Drilling Machine PriceUS$ 4200 - 4700MOQ: 1 Set
-
XYX-3 Wheeled Hydraulic Core Drilling Rig Wheels Portable Drilling MachineUS$ 4200 - 4700MOQ: 1 Set
-
XY-44A Hydraulic Drilling Rig Hydraulic Motor for Drilling RigUS$ 4200 - 4700MOQ: 1 Set
-
Hydraulic Water Well Drilling Rig XY-8 Hydraulic Drilling RigUS$ 4200 - 4700MOQ: 1 Set
1. Applications of XY-180 core drilling rig
The XY-180 drilling rig is designed on the basis of the XY-1A drill. It is a low speed and high torque portable drilling machine with oil pressure.
This drill rig is suitable for engineering geological survey of railway, hydropower, traffic, bridge, dam foundation and other buildings, geological core drilling and physical investigation, drilling holes for small holes and blasting holes, a small water well drilled.
2. Parameters of XY-180 core drilling rig
Drilling depth（m） |
180/150/120/90/70/30 |
Borehole diameter（mm） |
75/91/110/130/150/300 |
Maximum opening diameter（mm） |
375 |
Drill pipe diameter（mm） |
42/50 |
Spindle Speed (r/min) |
71/142/310/620 |
Spindle Stroke（mm） |
450 |
Upgrading Ability (KN) |
15 |
Diameter of steel wire（mm） |
12 |
Type |
gear pump |
Model |
YBC-12/80 |
Rated pressure (MPa) |
8 |
Rated speed (r/m) |
1500 |
Displacement（ml/r） |
8 |
Power supply |
ZS1115 diesel engine and 15kw motor |
