| Engine Model | KTA19-G3A |
| Configuration | In-line,4-stroke,4-valve,water-cooled |
| Aspiration | Turbocharged and air to air inter-cooled |
| Number of Cylinder,Bore×Stroke (mm) | 6-159×159 |
| Displacement (L) | 19 |
| Compression Ratio | 14.5:1 |
| Prime Power/Speed (kw/r/min) | 448/1500 |
| Standby Power/Speed (kw/r/min) | 504/1500 |
| Fuel consumption (g/kwh) | ≤210 |
| Oil Capacity (L) | 50 |
| Starting Method | Electric |
| Dimension(L×W×H) (m) | 3400×1250×2000 |
| Net weight (kg) | 3600 |
Advantage:
1)High conversion rate:100% copper alternator, class F insulation, high conversion rate.
2)Stable output :Smart AVR controller ensures stable voltage and less voltage waveform distortion.
3)Digital panel :Digital intelligent control panel with display of voltage, frequency and running time, makes easy maintenance.
4)Easy carrying:An open frame configuration means it’s easy to move and use.
5)Wide application:Various output sockets are available to meet all customers’ requirements
6)Air-preheating:With air-preheating device, it can be easily started at low temperature.
7)Optional items:
Remoter: control anytime anywhere freely.
ATS: automatic transfer from city power and gen-set power.
Intelligent digital control panel: with overload, over voltage, over current and low oil pressure protection function.
Chongqing Yangke Power Equipment specializes in producing and selling multi-functional diesel generator set, diesel engine, generators and generator spare parts. We have specialized in domestic production and OEM for ten years, our factory is located in Tongliang industrial park of Chongqing city,covering an area of 20,000 square meters.And our sales office is in Qianye building, Jiulongpo Commercial Centre.
We have franchise of CUMMINS, YUCHAI, SHANGHAI DIESEL ENGINE and NENJO, STAMFORD generator, which make our gensets are characterized bu small volume. light weight, low noise, low oil consumption, large power reserve, stable operation,and high reliability. We annual export 3,000 units genset for trading company in the past, and mainly to Southeast Asia, Middle East area, Africa and South America.We will always offer you the best price with higher quality machines.
Certicicate:
Warranty Policy:
Guarantee for one year or 1000 hours (accord to whichever reach first) from ex-factory date.During the guarantee period,our company will provide the free easy damaged spare part for problems caused by our quality of production or raw material except the damageable spare parts of diesel engine caused by customer's incorrect man made operation.After expiration, our company provides cost parts maintenance for genset.
Genset spare parts:
Application area:
FAQ:
Q:Are you a factory or a trading company?
A:We are factory.
Q:What kind of package do you use in delivery?
A:Less than whole container cargo,bubble film;whole container cargo,naked packing with plastic wrap.
Q:Can we customize the genset?
A:Yes.We can customize the color,style and configuration as your demands.
Q:What's the delivery time?
A:Delivery within 7 days after deposit confirmed.
