Dredging Machine 550 Mm Diam Diam Comminution Function

FOB Price

Negotiable

0 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Features:

1. Simple, rapid assembly and dismantling. Engineers available service abroad
2. Spare parts and floating pipe will be supported.
3. Reliable hydraulic system,easy to control
4. Efficient fuel consumption.
5. Siemens PLC control,One-man operation.

Dredger LOA	20.0m
Hull size(L×B×H)	13.0×5.2×1.5m
Main pontoon(L×B×H)	8.3×2.2×1.5m
Side pontoon (L×B×H)	11.0×1.5×1.5m
Structure	box-structure
Main engine brand & power	Cummins 224kw / Jichai 220kw / Weichai 220kw
Auxiliary engine brand & power	Customized
Harbor generator	Cummins 20kw /Jichai 20kw / Weichai 20kw
Total power	Cummins 244kw /Jichai 240kw / Weichai 240kw
Dredging pump	Warman Technology
Discharge pipe inner Dia.	200mm
Head	30m
Max. dredging depth	8m
Water flow	800m³/h
Solid sand capacity	160m³/h
Discharge distance	800m
Cutter head Dia.	1300mm
Cutter power	30kw
Draught	1.1m
Displacement	65T
Hydraulic control system	PLC Siemens
Wire rope pulling force (Lifting winch )*Quantity	40KN *1
Wire rope pulling force (Traversing winch )*Quantity	40KN *2
Operation room	Adjustable chair, movable side-window, air condition, PLC system, signal lights and floodlights
Total weight	50T
Total fuel oil consumption	34L/H

Our Services:

1,Pre-sale services: Passion &thoughtful

We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.

2,Sale services: Oversea Technicians

Oversea technicians will be sent to the jobsite for guiding the installation training operators and finishing the check and accept together with you.

3,After-sale services: Faithfulness

One year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
