High Quality Cheap Price Oil Pressure Gauges, Pressure Gauges Manometers
Description High Quality Cheap Price Oil Pressure Gauges, Pressure Gauges Manometers
Double-sided plastic pressure gauge manometer
Dial diameter: 60MM
Measuring range: 0 ~ 1KG, 2KG, 3KG, 4KG, 5KG, 7KG, 10KG, 15KG
mirror: PC mirror or glass
Shell material: PP plastic, acid, corrosion resistance, high resistance, good stability deformation temperature of 130 °C
table cover material: PP spinning bezel
Bourdon Tube Material: Phosphor Bronze
ambient temperature: When the maximum operating temperature 60 °C (in consideration of conduction properties), the ambient temperature of about -20 °C ~ 60 °C
connector thread: 1/2NPT with diaphragm and 1/4 npt without diaphragm
diaphragm material: Teflon, Viton, acid, corrosion
Accuracy class: ± 1.5%
Detailed Images High Quality Cheap Price Oil Pressure Gauges, Pressure Gauges Manometers
Specification High Quality Cheap Price Oil Pressure Gauges, Pressure Gauges Manometers
High Quality Cheap Price Oil Pressure Gauges, Pressure Gauges Manometers | |
Diameter |
60mm |
Measuring Range |
0~1KG, 2KGS, 3KGS, 4KGS, 5KGS, 7KGS, 10KGS, 15KGS |
Mirror |
PC Mirror of Glass |
Shell Material |
SS, acid, corrosion resistance, high resistance, good stability deformation temperature of 130 °C |
Table Cover Material |
Phosphor Bronze |
Ambient Temperature |
When the maximum operating temperature 60 °C (in consideration of conduction properties), the ambient temperature of about -20 °C ~ 60 °C |
Connector Thread |
1/2NPT with Diaphragm and 1/4NPT Without Diaphragm |
Diaphragm Material |
Teflon, Viton, Acid, Corrosion |
Accuracy Class |
± 1.5% |
