General Information:
SXWG Water Cooled Generator Insulation Tester is designed to test for water cooled generator, and insulation test onsite or laboratory.
Features:
√ LCD screen, English interface, easy to operate.
√ Auto calculates absorption ratio, and auto save the data per 15 seconds/ 1 minute/ 2 minutes/ 10 minutes.
√ Large output current, short circuit current is more than 20mA.
√ HV generating module is enclosed completely, build-in protective resistor, safe and reliable.
√ High anti-interference ability, suitable for onsite operating at HV substation.
√ Auto discharging after test completed, and discharging process to be monitored by real time.
√ Rechargeable battery, continuous working duty is 10-12 hours. Packing with charger.
Specifications:
√ Accuracy:±5%
√ Measuring range: 0.1M~1TΩ
√ Test voltage:2500V
√ Shot circuit current:>20mA
√ Measuring duration:1 minute~10 minutes(depends on measuring method)
√ Recharging supply: 180~270VAC ,50Hz/60Hz±1% (Mains supply or generator)
√ Battery: Large capacity Lithium battery(4000mAH/36V)
√ RS232 port.(option)
√ Working condition: Temperature -10~40ºC,Relative humidity 20~80%
Warranty: One year quality guarantee after shipment.
More details please kindly contact with Sansion Power.Thank you!
