Red Mining Wire Mesh Crimped Woven Wre Mesh Used In Quarries And Coal Yards
crimped woven wire mesh can be also known as the iron crimped mesh, stainless steel crimped mesh, black iron crimped mesh according to different materials. Crimped Wire Mesh is made in a variety of materials through crimping mesh machine, a kind of universal wire products with square or rectangular openings.
crimped woven wire mesh Specification:
1. Crimped wire mesh Material: Stainless steel wire, high carbon steel, carbon steel, nickel steel and nonferrous wire.
2. Crimped wire mesh Weaving type: pre-crimping before Weaving. In two-way separated wave bending, locked bending, flat-topped curved, two-way bending, one-way separated wave bending.
3.Crimped wire mesh Application: Screening in mine, petroleum, chemical, building and food industry. Used in machinery parts, packing, barbecue, hardware products, handicrafts, wire baskets, food machinery, road and railway, etc. Also used in screening and grading of solid materials and filtering of liquid and quarry,etc.
| Aperture mm | Aperture Tolerance mm | Wire mm | Edge Length mm | Weight kg/㎡ | ||
| Minimum | Maximum | Minimum | Maximum | |||
| 101.60 | 98.55 | 104.65 | 12.70 | 12.70 | 50.80 | 17.92 |
| 88.90 | 86.23 | 91.57 | 12.70 | 12.70 | 44.45 | 20.16 |
| 76.20 | 73.91 | 78.49 | 12.70 | 12.70 | 38.10 | 23.04 |
| 63.50 | 61.60 | 65.41 | 12.70 | 12.70 | 31.75 | 26.88 |
| 63.50 | 61.60 | 65.41 | 9.19 | 9.19 | 31.75 | 14.76 |
| 57.15 | 55.44 | 58.86 | 9.19 | 9.19 | 28.58 | 16.17 |
| 50.80 | 49.28 | 52.32 | 12.70 | 12.70 | 25.40 | 32.26 |
| 50.80 | 49.28 | 52.32 | 11.10 | 11.10 | 25.40 | 25.28 |
| 50.80 | 49.28 | 52.32 | 9.19 | 11.10 | 25.40 | 17.88 |
| 50.80 | 49.28 | 52.32 | 7.92 | 7.92 | 25.40 | 13.57 |
| 44.45 | 43.12 | 45.78 | 9.19 | 9.19 | 22.23 | 20.00 |
| 44.45 | 43.12 | 45.78 | 7.92 | 7.92 | 22.23 | 15.21 |
| 41.28 | 40.04 | 42.51 | 9.19 | 9.19 | 20.64 | 21.25 |
| 41.28 | 40.04 | 42.51 | 7.92 | 7.92 | 20.64 | 16.19 |
| 38.10 | 36.69 | 39.24 | 9.19 | 9.19 | 19.05 | 22.68 |
| 38.10 | 36.69 | 39.24 | 7.92 | 7.92 | 19.05 | 17.31 |
| 38.10 | 36.69 | 39.24 | 7.19 | 7.19 | 19.05 | 14.49 |
| 31.75 | 30.80 | 32.70 | 9.19 | 9.19 | 15.88 | 26.20 |
| 31.75 | 30.80 | 32.70 | 7.92 | 7.92 | 15.88 | 20.08 |
| 31.75 | 30.80 | 32.70 | 7.19 | 7.19 | 15.88 | 16.85 |
| 28.58 | 27.72 | 29.43 | 7.92 | 7.92 | 14.29 | 21.83 |
| 28.58 | 27.72 | 29.43 | 7.19 | 7.19 | 14.29 | 18.35 |
| 25.40 | 24.64 | 26.16 | 7.92 | 7.92 | 12.70 | 23.91 |
| 25.40 | 24.64 | 26.16 | 7.19 | 7.19 | 12.70 | 20.14 |
| 19.05 | 18.48 | 19.62 | 5.72 | 5.72 | 9.53 | 16.78 |
| 15.88 | 15.40 | 16.35 | 4.50 | 4.50 | 7.94 | 12.62 |
| 11.00 | 10.67 | 11.33 | 4.00 | 4.00 | 5.50 | 13.55 |
| 10.00 | 9.70 | 10.03 | 4.00 | 4.00 | 5.00 | 14.51 |
| 8.00 | 7.76 | 8.24 | 4.00 | 4.00 | 4.00 | 16.93 |
| 6.35 | 6.16 | 6.54 | 2.67 | 2.67 | 3.18 | 10.04 |
| 6.30 | 6.11 | 6.49 | 2.50 | 2.50 | 3.15 | 9.93 |
| 4.00 | 3.88 | 4.12 | 2.00 | 2.00 | 2.00 | 9.31 |
| 3.00 | 2.91 | 3.09 | 2.00 | 2.00 | 2.00 | 11.17 |
| 2.00 | 1.94 | 2.06 | 1.50 | 1.50 | 1.50 | 8.99 |
