The 1092 type -1575 toilet paper machine will be built and run.

1. The equipment covers an area of 200-500 square meters. Ensure sufficient water supply and power supply conditions. There are 3-5 factories and 4-6 workers.

2. The source of raw materials; the raw materials for production are extremely extensive. The local natural resources, such as waste paper, straw, wheat straw, waste paper, bamboo, wood, cotton stalk, bagasse, etc., can be fully utilized.

Two. Host introduction:

Instructions for use: toilet paper, corrugated paper, writing paper, burning paper, etc.

2. Net paper width: 1092mm

Working speed: 15 - 90 m / min

Quantitative: 13 - 80 g / square

Production capacity: 1 - 3 tons / day

Diameter of circular mesh: Phi 1000mm * 1450mm

Dryer diameter: Phi 1500mm * 1450mm

Three, pulping equipment:

1, 1.5 cubic pulper

2, 700 thrusters

3. Slurry pump

4, 250 type refiner

5, 0.9 square vibrating screen

6. Vertical mixer.

7. Vacuum pump

8, rinse machine

1575mm single cylinder single net high speed toilet paper machine with single blanket

Technical parameters:

Variety: toilet paper

Copy weight: 13-30g/m2

Width of net paper: 1575mm

Net width: 1950mm

Production capacity: 3-5 tons / day

Design speed: 180m/mm

Working speed: 120-160m/mm

Gauge: 2300mm

Type design: upside down slurry type.

Design standard: national standard export equipment

Main equipment structure:

1. Network Department: One stainless steel mesh cage of 1500mm *1950mm, one dense pressure mesh slot and one volt roll of 350mm *1950mm. Rubber hardness is 38 degrees + 2.

2. Drying section: a 2500mm *1950mm drying cylinder, a 450mm *2000mm roller, a pneumatic pressure device, rubber hardness of 90 + 2, drying cylinder equipped with double-layer hot air hood.

Three. Roll paper part: a 1000mm * 1950mm cold cylinder, a 280mm 280mm roll. The hardness of the rubber is 75 degrees + 2, which is rolled on the cold cylinder.

Four, transmission and control department: adopt AC frequency conversion speed regulation, step by step transmission, all digital closed loop control system.
