Central Processing MASTER FIELDBUS  Unit DSQC406 Abb

IN STOCK

DSQC406 ***Email: sales6@amikon.cn

PST85-600-70

General Information

Extended Product Type:PST85-600-70

Product ID:1SFA894008R7000

EAN:7320500255568

Catalog Description:PST85-600-70 SOFTSTARTER

Long Description:Softstarter PST85-600-70 for max 600V main voltage and 110 - 240V 50/60Hz control supply voltage

Dimensions

Product Net Width:186.000 mm

Product Net Height:390.000 mm

Product Net Depth / Length:270.000 mm

Product Net Weight:10 kg

Technical

Rated Operational Voltage:Main Circuit 208 ... 600 V AC

Rated Control Supply Voltage (Us):100 ... 250 V AC

Rated Control Circuit Voltage (Uc):DC Operation 24 V

Rated Frequency (f):Main Circuit 50/60 Hz

Control Supply 50/60 Hz

Rated Operational Power - In-Line Connection (Pe):(400 V) 45 kW

(500 V) 55 kW

Rated Operational Current - In-Line Connection (Ie):85 A

Rated Operational Power - Inside Delta Connection:at 400 V 75 kW

at 500 V 90 kW

Rated Operational Current - Inside Delta Connection:147 A

Service Factor Percentage:115 %

Overload Protection:Build-in electronic overload protection

Integrated Electronic Overload:Yes

Adjustable Rated Motor Current Ie:30 ... 115 %

Starting Capacity at Maximum Rated Current Ie:3xIe for 15s

Ramp Time:During Start 1 ... 30 second [unit of time]

During Start 1 ... 120 second [unit of time]

During Stop 0 ... 30 second [unit of time]

During Stop 0 ... 120 second [unit of time]

Initial Voltage During Start:30 ... 70 %

Step Down Voltage Special Ramp:100 ... 30 %

Current Limit Function:1.5 … 7xIe

Switch for Inside Delta Connection:Yes

Run Signal Relay:Yes

By-pass Signal Relay:Yes

Fault Signal Relay:Yes

Overload Signal Relay:Yes

Analog Outputs:0…10 volts

0…20 mA

4…20 mA

Signal indication ready to start/standby ON (LED):Green

Signal indication protection (LED):Yellow

Signal indication fault (LED):Red

Number of Starts Per Hour at 3.5*Ie for 7 sec. 50% ON Time 50% OFF Time:30

Communication:FiledBusPlug(Standard)

Degree of Protection:acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP00

Terminal Type:Main Circuit: Bars

Connecting Capacity Main Circuit:Hole Diameter 8.5 mm

Width and Thickness 17.5x5 mm

Connecting Capacity Control Circuit:Rigid 1x2.5 mm²

Rigid 2x1.5 mm²

Connecting Capacity Supply Circuit:Rigid 1x2.5 mm²

Rigid 2x1.5 mm²

Tightening Torque:Main Circuit 18 N·m

Supply Circuit 0.5 N·m

Control Circuit 0.5 N·m

Product Main Type:PST85

Environmental

Ambient Air Temperature:Storage -25 ... +70 °C

Operation 0 ... +50 °C

Battery Information:Button Cell Yes

Contains Cd<0.01 %

Contains Hg<0.01 %

Contains Pb<0.01 %

Weight 0.0031 kg
