SNAT7261 ***Email: sales6@amikon.cn
PST85-600-70
General Information
Extended Product Type:PST85-600-70
Product ID:1SFA894008R7000
EAN:7320500255568
Catalog Description:PST85-600-70 SOFTSTARTER
Long Description:Softstarter PST85-600-70 for max 600V main voltage and 110 - 240V 50/60Hz control supply voltage
Dimensions
Product Net Width:186.000 mm
Product Net Height:390.000 mm
Product Net Depth / Length:270.000 mm
Product Net Weight:10 kg
Technical
Rated Operational Voltage:Main Circuit 208 ... 600 V AC
Rated Control Supply Voltage (Us):100 ... 250 V AC
Rated Control Circuit Voltage (Uc):DC Operation 24 V
Rated Frequency (f):Main Circuit 50/60 Hz
Control Supply 50/60 Hz
Rated Operational Power - In-Line Connection (Pe):(400 V) 45 kW
(500 V) 55 kW
Rated Operational Current - In-Line Connection (Ie):85 A
Rated Operational Power - Inside Delta Connection:at 400 V 75 kW
at 500 V 90 kW
Rated Operational Current - Inside Delta Connection:147 A
Service Factor Percentage:115 %
Overload Protection:Build-in electronic overload protection
Integrated Electronic Overload:Yes
Adjustable Rated Motor Current Ie:30 ... 115 %
Starting Capacity at Maximum Rated Current Ie:3xIe for 15s
Ramp Time:During Start 1 ... 30 second [unit of time]
During Start 1 ... 120 second [unit of time]
During Stop 0 ... 30 second [unit of time]
During Stop 0 ... 120 second [unit of time]
Initial Voltage During Start:30 ... 70 %
Step Down Voltage Special Ramp:100 ... 30 %
Current Limit Function:1.5 … 7xIe
Switch for Inside Delta Connection:Yes
Run Signal Relay:Yes
By-pass Signal Relay:Yes
Fault Signal Relay:Yes
Overload Signal Relay:Yes
Analog Outputs:0…10 volts
0…20 mA
4…20 mA
Signal indication ready to start/standby ON (LED):Green
Signal indication protection (LED):Yellow
Signal indication fault (LED):Red
Number of Starts Per Hour at 3.5*Ie for 7 sec. 50% ON Time 50% OFF Time:30
Communication:FiledBusPlug(Standard)
Degree of Protection:acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP00
Terminal Type:Main Circuit: Bars
Connecting Capacity Main Circuit:Hole Diameter 8.5 mm
Width and Thickness 17.5x5 mm
Connecting Capacity Control Circuit:Rigid 1x2.5 mm²
Rigid 2x1.5 mm²
Connecting Capacity Supply Circuit:Rigid 1x2.5 mm²
Rigid 2x1.5 mm²
Tightening Torque:Main Circuit 18 N·m
Supply Circuit 0.5 N·m
Control Circuit 0.5 N·m
Product Main Type:PST85
Environmental
Ambient Air Temperature:Storage -25 ... +70 °C
Operation 0 ... +50 °C
Battery Information:Button Cell Yes
Contains Cd
Contains Hg
Contains Pb
Weight 0.0031 kg
