Home > Manufacturing & Processing Machinery > Paper Machinery > Paper Making Machine > Toilet Roll Making Machine

Toilet Roll Making Machine

Name: Toilet Roll Making Machine
Brand: yingfeng machine
SKU: 159067069
Availability: InStock

US$ 25000 - 88000 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

yingfeng machine

Place of Origin:

China

Model Number:

787-1092-1575-1760-1880-2400

Contact Supplier Request Quote Chat Now

Falong Paper Machinery And Equipment Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

tainjin/qingdao

Delivery Detail:

25 days

Product Details
Company Profile
Contact Us

Brand Name yingfeng machine

Place of Origin China

Model Number 787-1092-1575-1760-1880-2400

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Warranty 1 years

Weight 5-15tons

Dimension(L*W*H) 6500mm*4000mm*2000m

Product Type Other, Toilet Paper

Condition New

Processing Type Other, Toilet Paper Machine

Toilet Roll Making Machine

Specification:

Item Type	1092	1575	1760	1880	2400	2700	2900	3200	3500
Designing speed(m/min)	100	150	150	220	220	220	220	220	220
Working speed(m/min)	30-80	30-120	30-120	80-200	80-200	80-200	130-200	130-200	130-200
Grammage(g/m²)	13-30	13-30	13-30	13-30	13-30	13-30	13-30	13-30	13-30
Production capacity(t/d)	2-3	3-5	4-6	5-7	6-8	7-9	8-10	8-11.5	8.5-11.5
Dryer diameter (mm)	2500*1450	2500*2000	2500*2200	2500*2400	2500*2800	2500*3100	2500*3300	2500*3600	2500*3800
Power of main motor(KW)	30	37	45	45	55	55	75	75	75
Track gauge(mm)	1900	2400	2600	2800	3400	3700	3800	4100	4300

Type 1092-787-1575 toilet paper machinery, toilet paper production equipment: 1575 mm single cylinder single net single blanket high-speed toilet paper machine

Technical parameters:

Variety: toilet paper

Copy weight: 13-30g/m2

Width of net paper: 1575mm

Net width: 1950mm

Production capacity: 3-5 tons / day

Design speed: 180m/mm

Working speed: 120-160m/mm

Gauge: 2300mm

Type design: upside down slurry type.

Design standard: national standard export equipment

Main equipment structure:

1. Network Department: One stainless steel mesh cage of 1500mm *1950mm, one dense pressure mesh slot and one volt roll of 350mm *1950mm. Rubber hardness is 38 degrees + 2.

2. Drying section: a 2500mm *1950mm drying cylinder, a 450mm *2000mm roller, a pneumatic pressure device, rubber hardness of 90 + 2, drying cylinder equipped with double-layer hot air hood.

Three. Roll paper part: a 1000mm * 1950mm cold cylinder, a 280mm 280mm roll. The hardness of the rubber is 75 degrees + 2, which is rolled on the cold cylinder.

Four, transmission and control department: adopt AC frequency conversion speed regulation, step by step transmission, all digital closed loop control system.

Type 787 toilet paper machine, book paper machine

Equipment technical parameters:

Product categories: production of packaging paper, corrugated paper, toilet paper, superstition burning paper, napkins, cultural paper, etc.

Raw materials: raw pulp, waste paper, bamboo, straw, cotton poles, etc.

Equipment output: 1-1.8T/ days

Production ration: 15 grams ----80 grams

Equipment speed: 40----90 M / min

Introduction of 1092 type toilet paper and writing paper machine.

Instructions for use: toilet paper, corrugated paper, writing paper, burning paper, etc.

2. Net paper width: 1092mm

Working speed: 15 - 90 m / min

Quantitative: 20 - 105 g / square
