Full Automatic Blowing Machine

Full Automatic Blowing Machine thumbnail-1
Full Automatic Blowing Machine thumbnail-2
Full Automatic Blowing Machine thumbnail-3
Full Automatic Blowing Machine thumbnail-4
Full Automatic Blowing Machine photo-1
Full Automatic Blowing Machine photo-2
Full Automatic Blowing Machine photo-3
Full Automatic Blowing Machine photo-4
US$ 18000 - 22000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
WC
Place of Origin:
China
Model Number:
1 mold of two cavities
Contact Supplier Request Quote Chat Now
Honest Plastic Machine Shop
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name WC
Place of Origin China
Model Number 1 mold of two cavities
After-sales Service Provided Engineers available to service machinery overseas
Warranty 1year
Weight 2000kg
Dimension(L*W*H) 2.5x1.6x2m
Voltage 380 or order
Application Bottle
Condition New
Power(W) 22kw
Automatic Yes
Blow Moulding Type Stretch Blow Moulding
Plastic Processed PET

技术参数technical parameter

A1L-1

A1L-2

A1L-4

A1L-6

A2L-1

A2L-2

A2L-4

A2L-6





制品容量Container volume



1L

1L

1L

1L

2L

2L

2L

2L





开模行程Clamping stroke

105mm



105mm

105mm

105mm

140mm

140mm

140mm

140mm





最大拉伸Max.stretching stroke

360mm

360mm

360mm

360mm

410mm

410mm

410mm

410mm





最大模厚 Mold thickness

160mm

160mm

160mm

160mm

180mm

180mm

180mm

180mm





模具腔数 Number of cavities

1

2

4

6

1

2

4

6






理论产量Theoretical output（BPH）

1200

2400

4000

6000

1100

1900

3500

5500





瓶子直径 Container diameter

20-90mm

20-90mm

50-125mm

50-125mm


瓶子高度 Container height

30-360mm

30-360mm

40-410mm

40-410mm



瓶口尺寸 Neck diameter

18-38mm

18-38mm

28-58mm

28-58mm



电源Voltage standard

380v/3PH/50HZ or special order

总功率Total power(kw)

12

18

30

40

14

22

36

48





实际使用功率 Use power(kw)

6

10

16

26

7

12

18

26





低压系统 Low air compressor

1.2m³/min 10bar

2.0m³/min10bar

1.2m³/min 10bar

2.0m³/min10bar

高压系统 High air compressor

1.6m³/min30bar

2.4/3.6³/min 30bar

1.6m³/min 30bar

3.6m³/min 30bar

主机尺寸 Machine size(L*W*H)

1.8(2.4)X1.5X1.8m

3.5(4.2)x1.5x1.8m

2.2(2.8)x1.6x1.9m

(3.5)4.8x1.6x1.9m

上料机尺寸Preform loader size

1.1x1.2x2.2m

1.1X1.2X2.5m

1.2x1.2x2.2m

1.1X1.2X2.5m

净重 Net weight

1.2T

1.6T

2.3T

3.5T

1.5T

1.8T

2.5T

3.6T




Product Tags: bottle blowing machine , pet bottle blowing , mineral water bottle , drink bottle machine
