Testing Equipment MF-FS93 Fluorescence Spectrophotometer for Laboratory
US$ 5000 - 6000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Medfuture
Place of Origin:
China
Model Number:
MF-FS93
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
10 days
Related Products
-
MF-FS93 Fluorescence SpectrophotometerUS$ 1000 - 2000MOQ: 1 Set -
MF-FS97series Fluorescence Spectrophotometer for LaboratoryUS$ 2000 - 3000MOQ: 1 Set
-
MF-AAS320N Atomic Absorption SpectrophotometerUS$ 2000 - 3000MOQ: 1 Set
-
MF-5100 Series High Performance Liquid ChromatographyUS$ 2000 - 20000MOQ: 1 Set
-
MF-SZM45 Stereo Zoom MicroscopeUS$ 250 - 500MOQ: 1 Set
Brand Name
Medfuture
Place of Origin
China
Model Number
MF-FS93
MF-FS93 Fluorescence Spectrophotometer
Features For MF-FS96PRO
1.Two operation modes fluorescence intensity and luminous intensity.
2.365nm exciting wavelength，Raman peak of water S/N ≥150.
3.10 stages emission spectrum scanning.
4. Support off-line mode and on-line mode.
Features for MF-FS93
1. 1200 line diffraction grating emission monochromator .
2. LED is a cold-light source with longevity, lower background & reliability, prevent from thermo-pollution.
3.Automatic zero adjustment and automatic background subtraction,
4. Eight stage sensitivity adjustment, Real time fluorescence value display and concentration print out, Extra wide dynamic range of fluorescence value ensures accurate measurement of minute changes in micro samples.
Technical Parameters
| Model | MF-FS96PRO | MF-FS93 |
| Light source | Hamamatsu 150W Xenon lamp | LED Light |
| Excitation Wavelength | Interference optical filtera) Standard set is equipped with an interference optical filter of central wavelength at 365nm and 10nm bandwidthb) An optional interference optical filer of 25mm diameter of wavelength of 250~700nm can be provided on users demand. |
LED options a) Standard set includes LED at wavelength 365nm b) The A set includes LED wavelength at 365nm, 376nm, 392nm, 405nm c) Customizable wavelength from 360nm to 600nm |
| Emission Monochromator | C-T diffraction grating(Em 200~900nm，bandwidth 10nm) | 360~650nm (C-T diffraction grating) |
| Wavelength Accuracy | ±1nm | ±2nm |
| Wavelength Repeatability | ≤0.5nm | ≤1nm |
| Sensitivity | Raman peak of water in 1 cm quartz fluorescence cuvette with S/N≥150 | 1×10-9 g/ml (Standard aqua of the sulfuric acid Quinine, 12nm bandwidth) |
| Linear measurement | ≥0.995r | |
| Stability | Better than 1.5%/10min | better than 3%/10min |
| Response Time | (0.1~4) s 6 stages adjustable | (0.1~4) s |
| Fluorescence display value | 0.00~600.00 | 0.00~250.00 |
| Standard Accessories | 365nm filter (Preassembled)*1F96PRO software package*1 Power cable*1, USB interface*1Quartz fluorescence sample cell10mm*1 | Glass fluorescence cuvette 10mm*1RS232 serial port |
| Optional Accessories | Fuses(2A/5A), 200~700nm interference optical filter (φ25mm)Quartz fluorescence sample cell10mmMulti-function fluorescent sample rack holder, Membrane sample rack, Powder sample rack, Sample cell jacket, Octave Filters200uL microcentrifuge tube accessoryUpconversion fluorescent accessory | Data processing software package (pack, for PC), Fuses(2A) Quartz fluorescence cuvette10mmOptional LED A Set includes: 365nm、376nm、392nm、405nm |
| Power Supply | AC220V/110V±10%, 50/60Hz | |
| Consumption | 190 | 35 |
| Packing Size(W*D*H) mm | 550*510*365 | 450*420*280 |
| Gross Weight(kg) | 14 | 9 |
