Help CenterManufacturing LED Light Bar Flexible PCB For Train
Related Products
· Brand Name: Customized
· Min.Order Quantity: No
· Supply Ability: 30~50 thousand ㎡/Month
· Port: Shenzhen
· Service: EMS/OEM/ODM
· Payment Terms: T/T,Paypal,WU etc.
· Layer: 2
· Base Material: polyimide
· Copper Thickness: 0.5oz
· Board Thickness: 0.25mm
· Solder Mask Color: Black cover film
· Silkscreen Color: White
· Surface Finishing: OSP
· Test Way: 100% Test
· Standard: IPC-Class2/Class 3
This LED PCB Board is a Manufacturing Black LED Light Bar Flexible PCB For Train,used for Lighting Production,A LED PCB Circuit Board with OSP Surface Finishing is a coating between a component and a bare led pcb circuit board,KingSong Tehnology as a professional LED PCB Manufacturer are not only offer Led Strip Pcb Suppliers,but also Flexible Pcb For Led or Led Strip Flexible Pcb etc.
1.Detail Flex / Rigid-flex PCB Manufacturing Capacities:
No. |
Item |
Description |
1 |
Layer |
Flex board: 1-6Layers |
2 |
Material |
CCL, PI, PET, PEN, FR-4 |
3 |
Final Thickness |
Flex board: 0.002″ – 0.1″ (0.05-2.5mm) |
4 |
Surface Treatment |
Lead-free: ENG Gold; OSP, Immersion silver, Immersion Tin |
5 |
Min Trace |
Inner: 0.5oz: 4/4mil Outer: 1/3oz-0.5oz: 4/4mil |
6 |
Min Width /Clearance |
1oz: 5/5mil 1oz: 5/5mil |
7 |
Min Hole Ring |
Inner: 0.5oz: 4mil Outer: 1/3oz-0.5oz: 4mil |
8 |
Copper Thickness |
1/3oz – 2oz |
9 |
Max / Min Insulation Thickness |
2mil/0.5mil (50μm/12.7μm) |
10 |
Min Hole Size and Tolerance |
Min hole: 8mil |
11 |
Min Slot |
24mil x 35mil (0.6×0.9mm) |
12 |
Solder Mask Alignment Tolerance |
±3mil |
13 |
Silkscreen Alignment Tolerance |
±6mil |
14 |
Silkscreen Line Width |
5mil |
15 |
Gold Plating |
Nickel: 100μ” – 200μ” Gold: 1μ”-4μ” |
16 |
Immersion Nickel / Gold |
Nickel: 100μ” – 200μ” Gold: 1μ”-5μ” |
17 |
Nickel: 100μ” – 200μ” Gold: 1μ”-5μ” |
Silver: 6μ” – 12μ |
18 |
OSP |
Film: 8μ” – 20μ” |
19 |
Test Voltage |
Testing Fixture: 50-300V |
20 |
Profile Tolerance of Punch |
Accurate mould: ±2mil |
2.Delivery time:
Flexible pcb:5-9 working days,
Rigid-flex pcb:10-20 working days.
3.Package:Inner vacuum packing,Outer standard carton box packing.
4.Shipping:
A:By DHL,UPS,Fedex,TNT etc.
B:By sea for mass quantity according to customer’s requirement.
5.If need quotation for your PCB projects,pls provide following info:
A:Quote quantity,
B:Gerber file in 274-x format,
C:Technical requirement or parameters(material,layer,copper thickness,
board thickness,surface finishing,solder mask/silkscreen color…)
