Home > Industrial Equipment & Components > Valve > Ball Valve > 3 PCS STAINLESS STEEL FLANGE BALL VALVE
3 PCS STAINLESS STEEL FLANGE BALL VALVE
US$ 4 - 100
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
BKVALVE
Place of Origin:
China
Model Number:
BK-017
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
7 days
Related Products
-
STAINLESS STEEL INNER THREADED1 PCS BALL VALVEUS$ 4 - 100MOQ: 1 Piece -
STAINLESS STEEL SS304/SS316 FEMALE 2 PCS BALL VALVEUS$ 4 - 100MOQ: 1 Piece
-
3PCS STAINLESS STEEL THREADED END BALL VALVEUS$ 4 - 100MOQ: 1 Piece
-
PNEUMATIC STAINLESS STEEL FLANGE BALL VALVE – BKVALVEUS$ 4 - 100MOQ: 1 Piece
-
DIN 3352 F4 RESILIENT SEATED FLANGED GATE VALVESUS$ 4 - 100MOQ: 1 Piece
Brand Name
BKVALVE
Place of Origin
China
Model Number
BK-017
Material
Casting
Application
General
Structure
Butterfly
Standard or Nonstandard
Standard
Pressure
Other, normal pressure
Power
Manual
Port Size
tianjin
Media
Water
Temperature of Media
Normal Temperature
pneumatic stainless steel flange ball valve Features
24 months guarantee
| Name: | flange end floating ball valve |
| Size: | DN15-DN250 |
| End flange | ANSI B 16.1,EN1092,AS2129 |
| Face to Face | ANSI B 16.10 |
| Top flange | ISO 5211 |
| Normal pressure: | PN1.0/1.6MPa(150/200PSI); Class 125/150; JIS 5K 10K 16K 20K; Table D/E |
| Body: | CI/DI/WCB/ALB/CF8/CF8M |
| Disc: | DI/ALB/Rubber lined Disc/1.2501/1.4529/CF8/Hastelloy Alloy/Monel |
| Stem: | 410/416/304/431/17-4PH/316/monel |
| Seat: | NBR/Hypalon/EPDM/Neoprene/NR/Wear-Resistant EPDM/Viton/Silicon/Heat-Resistant EPDM/White EPDM/EPDM(NSF)/PTFE |
| Suitable temperature: | -10~200 |
| Medium: | Fresh water, sewage, sea water, air, vapor, food, medicine, oils, alkalis, salt etc. |
The top flange of the valves can be applied to manual , worm gear , pneumatic and electric actuator .
The dimensions of D1 and n-d are the mounting specification , which can be China standard GB , ISO standard , ANSI standard , DIN standard ,JIS standard , AS standard and BS standard
