Sawdust crusher introduction
sawdust crusher is to crush wood logs,wood lumps,wood branches,tree roots,straw,salks and so on into small pieces.
There are two feed inlets for materials of different sizes.
It is mainly consisted of upper&lower engine body, side discharging outlet, centre rotor, low
pressure fan, underframe etc.
It is an ideal equipment in line of producing various wood products such as wood blocks, wood pellets, biomass briquette etc.
Sawdust crusher features
Double layer case, external case is made of thicken steel plate, interior case is made of wear-resistant scale board.
Center rotor is made of moving blade, fixed blade, main axis and axis pin.
Compact structure, easy operation, high efficiency.
Automatic feed system can be added according to customer`s demands.
Technical Parameters
Type 600 800 900 1000 1200
Powerï¼kwï¼ 22+4 30+5.5 37+7.5 45+11 55+11
Rotating Speedï¼h/minï¼ 2600 2600 2400 2400 2400
Capacityï¼kg/hï¼ 800-1200kg 1800-2000kg 2000-3000 kg 3000-4000 4000-6000kg
Feeding size According to your materials
Weightï¼kgï¼ 1300 2000 2800 3500 4500
Dimensionsï¼mï¼ 2.5x2.0x1.2 2.6x2.1x1.5 2.8x2.2x1.5 3.0x2.5x1.7 3.4x2.8x2
