Dongguan Billion Customized Production of Hydraulic Lift Vacuum High-speed Dispersive Machine

Hydraulic lifting and dispersing machine performance:

(1) the column lifting is stable and flexible, convenient for operation and maintenance, safe and reliable positioning.

(2) the mixing system has small vibration and low noise, and the speed of mixing shaft can be adjusted.

(3) according to the requirements of users, one machine can be equipped with more than one container and used alternately.

The sawtooth circular dispersing disc of the high-speed dispersing machine is dispersed in the container at high speed to complete solid-liquid dispersion, wetting, depolymerization and stabilization process.

(1) making the slurry flow in a rolling circle, producing strong vortices, and the particles on the slurry surface spiral downward to the bottom of the vortex.

(2) a turbulent area is formed at the edge of the dispersal disk 2.5-5mm, and the slurry and particles are subjected to strong shear and impact.

(3) outside the region, two upper and lower beams are formed, and the slurry is fully circulated and turned over.

(4) the dispersing disk of the dispersing machine is laminar flow below, and the slurry layer with different flow velocity diffuses each other, thus dispersing. High speed dispersing machine has many functions, such as hydraulic lifting, 360 degree turning, stepless speed regulation and so on. At the same time, 2-4 containers can be configured, the hydraulic lift stroke 1000, 360 degree of rotation function can better meet one machine multi use, can change from one cylinder to another in a very short time, greatly improve the work efficiency, but also reduce the labor intensity.
