Help CenterSpeed Pulse Signal Converter IC Sy-S3 -P2 -O1
Related Products
-
Displacement Sensor Position Sensor Signal ConditionerNegotiableMOQ: 2 Pieces -
Potentionmeter Signal Isolator Resistance Signal TransmitterNegotiableMOQ: 2 Pieces
-
(2: 1) Wide Input Range 3W Voltage Transmitter Dw3-48s05NegotiableMOQ: 2 Pieces
-
Low Cost 2-Wire Passive 4-20mA to Voltage Singnal Converter Sy 4-20mA-O2.5NegotiableMOQ: 2 Pieces
-
AC to DC 0-10mA/4-20mA/0-5V/0-10V Output TransmitterNegotiableMOQ: 2 Pieces
Sine Wave Sawtooth Wave Signal Low Cost Dual Isolation Transmitter IC SY S-P-O Series
Features
1)Speed sensor signal input directly, square wave signal output.
2)Sine wave, sawtooth wave signal input, square wave signal output.
3)200mV peak weak signal amplification and shaping.
4)Maintain the original signal frequency, fast response.
5) Power supply and signal channel 3000VDC Two-port Isolation
6)Power supply:5V/12V/15V/24V,etc.
7)Low cost, ultra-small size, no need to adjust, easy to use, high reliability
8) Standard SIP12 Pin, meet UL94V-0 flame-retardant package
9) Industry temperature range:-25~+70 deg.C
Applications
1)Speed sensor signal transformation.
2) Locomotive speed measurement.
3)Auto ABS anti-lock
4)Speed signal amplification
5)Motor Speed Control
6)CNC machine tool spindle and alarm monitoring.
7)Transmission and transmission without distortion.
