Detailed specification of the Car Spray Booth Car Spray Booth price,Car Spray Booth cost,Car Spray Booth design
1. we are factory manufacturer;
2. the burner both are Italy RIELLO burner;
3. over 12 years manufacturing experience;
4. have export experience;
5. we have stock for the booth parts;
6. fast delivery due to the stock of the booth parts.
Model |
HY-CB75A |
Inside Size |
6900(L)*3900(W)*2700(H)mm |
Outside Size |
7000(L)*5400(W)*3400(H)mm |
Wall Panel |
double skinned with insulation(EPS or Glass-wool), tongue and groove interlock construction, thickness: 50mm. |
Doors |
3-fold main doors, 3000(W) *2600(H) mm. One personnel door, 800(W)*2000(H)mm |
Basement&floor |
Raised metal-base (300mm high) with complete grating floor |
Intake |
One turbo fan, air capacity: 25000cbm, motor:7.5kW, direct drive |
Extract |
One turbo fan, air capacity: 25000cbm, motor: 7.5kW,direct drive |
By-pass |
Pneumatic damper from spraying to baking cycle |
Heating System |
Stainless heating converter, 60-80degree working temperature. Italy Riello one-stage oil burner.(gas burner optional) |
Filter System |
4 sorts of filters: Pre-filter, ceiling filter, floor paint-stop filter, extract paint-stop filter |
Lighting |
Upper inclined lights, 8units, 4*36W each |
Control System |
Bake temperature settings, bake timer, hour meter, over temperature alarm, indicator lights, emergency stop and so on. |
Remarks |
Type 1: 300mm high raised metal-base with full 2pcs ramps outside. (Standard) Note: Any size! Any Structure! All possible! |
