Model:HT-6013
Name: Helmet Projection and surface Friction Testing Machine
Suit standard : According to ECE R22.05 standard requirement
Purpose:
Helmet surface friction testing machine is will take helmet as certain force press on the fixture (this fixture can move), fixture surface install with abrasive paper of standard specified particle size, then will make the test helmet through from abrasive paper surface for certain speed , thereby to judge resistance friction performance of helmet
Technical parameter:
1.This machine can be used for protruding area and surface friction test
2.The mass of Impact weight:15kg
3.The free drop height:500mm
4.Mass of loading system:400N (40.8kg)
5.Electro-magnet controlled release system
6.The lever guiding system, stick the abrading material onto its outer
7.Adjustable headform support
8.Touch screen control
