2018 manufacturer provide M12 d code 4 pin male and female t branch cable connector
• M12 Circular connector according to IEC 61076-2-104
• M12 circular connector with M12*1.0 screw locking
• Equivalent to Binder, Phoenix, Lumburger automation...
• Waterproof rating is IP67/IP68, protected from dust and water during immersion, resistant to many oils and chemical
Generally Description:
Connector Series: M12
Standard: IEC 61076-2-104
Coding: D
Gender: Male and Female
Connector Design: Cable pllug
Connector Locking System: Fix screw
Waterproof Rating: IP67/IP68
Normal Temperature: -10℃~+80℃
Material:
Connector Body: TPU
Male Contacts: Brass with gold plated
Female Contacts: Phosphorus copper with gold plated
Screw/Nut: Brass with nickel plated
Waterproof 0-ring: FKM
Electrical data:
Contact Resistance: ≤5mΩ
Insulation Resistance: ≥100MΩ
Rated Current: 3A~1A
Rated Voltage: 60V~30V
