Male b Code 5 Pin M12 Plastic Housing Shielded Cable Connector
US$ 0.9 - 1.3
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Brand Name:
Indus-connector
Place of Origin:
China
Model Number:
20180816
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Equivalent to Binder M12 5 Poles High Quality Female Sensor Round Connector for SatelliteUS$ 0.9 - 1.3MOQ: 50 Pieces -
M12 Male d Type Moulding Waterproof 4 Pin Insert Shielded Connector for IndustryUS$ 0.9 - 1.3MOQ: 50 Pieces
-
Customized Shielded 4poles M12 Female d Code Moulding Connector for MedicalUS$ 0.9 - 1.3MOQ: 50 Pieces
-
Hot Sale M12 3 Poles Waterproof a Code Male Moldable Connector for SensorUS$ 1.0 - 1.9MOQ: 50 Pieces
-
High Quality 3 Poles Watertight Female Shielded Molded Connector for MedicalUS$ 1.0 - 1.9MOQ: 50 Pieces
Brand Name
Indus-connector
Place of Origin
China
Model Number
20180816
Type
Other, M12
Application
Automotive
Gender
Male
• M12 Circular connector according to IEC 61076-2-104
• M12 circular connector with M12*1.0 screw locking
• Equivalent to Binder, Phoenix, Lumburger automation...
• Waterproof rating is IP67/IP68, protected from dust and water during immersion, resistant to many oils and chemical
Generally Description:
Connector Series: M12
Standard: IEC 61076-2-104
Coding: A
Gender: Female
Connector Design: Cable plug
Connector Locking System: Fix screw
Waterproof Rating: IP67/IP68
Normal Temperature: -10℃~+80℃
Material:
Connector Body: TPU
Female Contacts: Phosphorus copper with gold plated
Screw/Nut: Brass with nickel plated
Waterproof 0-ring: FKM
Electrical data:
Contact Resistance: ≤5mΩ
Insulation Resistance: ≥100MΩ
Rated Current: 3A~1A
Rated Voltage: 60V~30V
