Descriptions:
In industrial applications, more and more complex movements require the use of twisted or three-dimensional flexible cables, and require these cables to have a similar service life when used in straight-line towline systems.
The core, twist, shield and sheath material must be able to withstand the bending forces generated during bending and the radial pressure changes caused by torsional motion. For this reason, different "soft" structural elements such as viscose fibers, PTFE elements, or other filler elements are used in highly flexible robotic cables to absorb torsional forces.
Applications:
Torsion cable for robotic systems, automatic handling equipment and for mechanical, no special changes. Torsion cables can be used indoors and outdoors. Torsional cables have areas where corrosive mineral oil is leaking and where the cables are exposed to high mechanical stresses.
Parameters:
Conductor: Highly flexural strength of bare copper strand (in accordance with EN 60228)
Insulating material: Insulating TPE material with high mechanical eng_properties
Unit shield: high torsional strength of tinned copper wire braided shield, optical coverage of 85%
Outer sheath: low viscosity, halogen-free, PUR-based mixture, particularly abrasion resistant and highly flexible for towline
Operating temperature range: (mobile installation) -25 ° C to +80 ° C with a bend radius of 10 x d
Operating temperature range: (fixed laying) -40 ° C to +80 ° C, bending radius of 4 x d
Maximum speed: 180 ° / s
Reverse the maximum acceleration: 60 ° / s2
Travel distance: for robotic and 3D motion applications, Class 6
Torsion: Each cable length can be twisted by ± 180 °
Radiation resistance: high
Rated voltage: 300/500 V (according to DIN VDE 0245)
Features:
All highly flexible robotic cables are tested for 3 million rounds of motion in a test that takes 1 meter long and does a +/- 180 ° twist test. In addition, we conducted another test, that is, the cable placed in a length of about 2500 mm towline, and then the 270 ° twist, during which the centripetal force will make the cable to withstand high Of the load and the heavy impact, so in general, this situation will usually occur in the application of industrial robots.
