Description
A Fire hose coupling is connector on the end of hose to connect or couple it with another hose or with a tap or hose appliance, such as irrigation sprinkler. It is usually made of steel,brass,stainless steel,aluminium or plastic.Used for combining water band with water band ,fire hydrant ,water lance and the fire-fighting truck so that they are to supply water or foam misture for putting out fire.
Technical Specification
Model |
KD |
KY |
KN |
KJ |
|||||
Diameter(mm) |
DN50 |
DN65 |
DN80 |
DN50 |
DN65 |
DN50 |
DN65 |
DN50/ DN65 |
DN65/ DN80 |
Working Pressure(Mpa) |
1.6 |
||||||||
Testing Pressure(Mpa) |
2.4 |
||||||||
Available Medium |
Clear Water, Foam mixed liquid |
||||||||
Fire Hose Coupling Type |
Inlet |
Outlet |
|
British/John Morris Coupling |
2.5”BS336 |
Φ63.5 |
2”BS336 |
Φ51 |
|
1.5”BS336 |
Φ38 |
|
2.5”BS336 |
Φ51 |
|
2.5”BS336 |
Φ38 |
|
2”BS336 |
Φ38 |
Fire Hose Coupling Type |
Inlet |
Outlet |
|
American(ANSI Pin)Fire Hose Coupling |
2.5”NH |
Φ63.5 |
2”NH |
Φ51 |
|
1.5”NH |
Φ38 |
Fire Hose Coupling Type |
Inlet |
Outlet |
|
Nakajima(Machino) fire hose coupling |
2.5” |
Φ63.5 |
2” |
Φ51 |
|
1.5” |
Φ38 |
Fire Hose Coupling Type |
Inlet |
Outlet |
|
Forestry Fire Hose Coupling |
1.5” |
Φ38 |
1.5” |
1.5” BSP |
|
1.5” |
1.5” NPSH |
|
1.5” |
F1.5” BSP |
Fire Hose Coupling Type |
Inlet |
Outlet |
|
Gost(Russian) Fire Hose Coupling |
2” |
Φ50 |
2.5” |
Φ70 |
|
3” |
Φ80 |
|
4” |
Φ100 |
Fire Hose Coupling Type |
Inlet |
Outlet |
UNI Fire Hose Coupling |
UNI70 |
Φ70 |
UNI45 |
Φ45 |
Fire Hose Coupling Type |
Inlet |
Outlet |
Storz Fire Hose Coupling |
4” STORZ |
Φ100 |
3” STORZ |
Φ75.5 |
|
2.5” STORZ |
Φ63.5 |
|
2” STORZ |
Φ51 |
|
1 3/4” STORZ |
Φ44.5 |
|
1” STORZ |
Φ38 |
