Parameter
Input Voltage |
220V/ 110V |
Working Voltage |
DC 24V |
Ambient Temperature |
-50 ~ +50 Celsius degree |
Gate Width (per wing) |
|
Gate Weight (per wing) |
|
Regular Components |
2 motors, 1 panel, 2 remote controllers |
Optional Parts |
IR sensor, storage battery, visual doorbell, card reader, fingerprint reader |
Weight (kg) |
23 |
Dimension (cm) |
42*32*31 |
Package |
carton with foam |
Basic functions:
1. open up or close up in sequence
2. Automatically stopping function against extra resistance
3. Infrared protection interface
4. back-up power supply interface
5. operating time limit protection
6. optional operation mode for single or dual wing
7. adjustable interval setting in sequent close-up
8 adjustable operating time limit setting
9. automatically stopping and running reversely against excessive resistance during closing-up
10. interface for card reader and underground detector
11. adjustable time setting for automatic close-up function
Product features:
1. Easier to drive the gate: The motor is mounted on the far end from the hinge point.
2. Special sliding groove: This enables the tolerance to the unevenness of road surface up to
90mm, maximum tolerance up to 300mm.
3. Unlimited opening angle: As far as the opener is concerned, the opening angle can be
greater than 180°.
4. Automatic locking unit: This unit combines the closing and the locking actions.
5. Optional manual operation: At power cut, the operation mode can be easier switched to
manual with a key.
6. Convenient installation: Can be mounted to any gate regardless of the condition of gate
posts or gate itself.
Intelligent Functions:
1. Single or dual gate arm close or open operation mode: The user can make the choice with
the remote controller.
2. Prevent mal-operation: The opener cvan distinguish any overlapped instruction.
3. Reminding the close-up: At fully closing and locking of the gate, the controller will remind the
user by giving a warning tone of "Di".
4. Optional infra-red protection: When linked with infrared detector, the opener can pause
operation whenever any passenger or vehicle is in between the gate.
5. Compatible with auto-identification system: Linked with camera, card reader, etc., the
opener can jointly achieve the purpose of safety and antitheft, entry or exit.
6. Lock-up of control box: Use the remote controller to deactivate the panel buttons to
prevent unauthorized operation of the gate.
7. Anti-Entrapment protection: The opener will automatically stop running in the case.
8. Overtime protection: To protect the motors, a one-way operation will be automatically
terminated at the 60th second.
9. Automatic closing (optional function): The user can choose to activate this function by
presetting in the control box.
10. Compatible with stand-by power supply: The opener can work with stand-by power supply,
such as storage battery
