High Quality RG59 Coaxial Cable With DC Power Cable
US$ 5.5 - 10.5
MOQ: 200 Rolls
Key Specifications
Get Latest Price
Brand Name:
RG6
Place of Origin:
China
Model Number:
COAXIAL CABLE
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
15 days
Related Products
-
RG59 RG6 RG11 Coaxial CableUS$ 5.5 - 10.5MOQ: 200 Rolls -
RG59 RG6 RG11 Coaxial CableUS$ 5.5 - 10.5MOQ: 200 Rolls
-
RG6 Coaxial Cable/Computer Cable/Data Cable/Communication Cable/Audio Cable/ConnectorUS$ 5.5 - 10.5MOQ: 200 Rolls
-
RG59 Coaxial Cable/Communication Cablee/Connector+0.5mm,0.75mm Power CableUS$ 5.5 - 10.5MOQ: 200 Rolls
-
RG59 Coaxial Cable With DC Power CableUS$ 5.5 - 10.5MOQ: 200 Rolls
Brand Name
RG6
Place of Origin
China
Model Number
COAXIAL CABLE
Type
Insulated
Application
Other, Communication
Insulation Material
PE
Conductor Material
Copper Clad Steel
Conductor Type
Solid
rg59 coaxial cable with power
Construction
| Inner conductor | Plain copper | Φ0.81 ±0.025mm |
| Dielectric | F. PE | Φ3.7 ±0.10mm |
| Outer conductor | CCA | 80x0.12mm |
| Shield coverage | 65% | |
| Sheath | PVC o rLSZH | Φ6.00±0.10mm |
Electrical & Mechanical Characteristics
| Impedance | 53±3 Ohm0 | |
| Nominal capacitance | 94pF/m | |
| Velocity of propagation | 66% | |
| Insulation resistance | >2000 Mohm.Km | |
| Inner conductor resistance | 35.0 Ohm/Km | |
| Outer conductorresistance | 16.5Ohm/Km | |
| Test/Operatig Voltage(max) | 5KV/2KV | |
| Operating temperaturerange | -30°C-+70°C | |
| Copper Weight | 18.7Kg/Km | |
| Cable weight(approx.) | 39.9Kg/Km | |
| Screening effectiveness | 100-900MHz | >55dB |
Attenuation
| Frequency(MHz) | Attenuation(dB/100m) | Attenuation(dB/100ft) |
| 50 | 9.1 | 2.77 |
| 100 | 13.1 | 3.99 |
| 200 | 19.4 | 5.91 |
| 400 | 28.4 | 8.66 |
| 500 | 32.2 | 9.82 |
| 600 | 35.7 | 10.88 |
| 860 | 44.8 | 13.66 |
| 1000 | 49.0 | 14.94 |
Return Loss
| 30-300MHz | >26dB |
| 300-600MHz | >25dB |
| 600-900MHz | >24dB |
Welcome to visit our factory and get our samples.
Your inquiry will be answered within 24 hours .Wishing to be your long- term partner ,please feel free to contact me ,we will do our best for you.
Choose us, won't make you disappointed:
1.6years manufactory experience
2.OEM/ODM available
3.Steady product quality
4.Strict quality control
5.Strictly conform to CE,ROHS,Iso9001
6.Quick delivery time(20ft,25days)
