Ti Grade 2 (CPTi) Unalloyed titanium
-----The pure titanium most used. The best combination of tensile strength, ductility, weld-ability and cold forming properties.
Chemical Composition (%) ASTM B348
Grade |
Carbon Max |
Oxygen Max |
Nitrogen Max |
Iron Max |
Hydrogen Max |
Aluminum Max |
Vanadium Max |
Grade2 |
0.03 |
0.25 |
0.08 |
0.30 |
0.015 |
/ |
/ |
Annealed Mechanical Properties ASTM B348
Grade |
Tensile Min |
Yield Min |
Elongation in 4D Min % |
Reduction of Area min % |
Grade 2 |
50Ksi (345Mpa) |
40Ksi (275Mpa) |
20 |
30 |
Ti Grade 5 -----Titanium Alloy (Ti-6Al-4V) (6% aluminum, 4% vanadium)
----- One of the most used titanium alloy is an alpha-beta alloy containing 6% Al and 4% V, due to its excellent combination of corrosion resistance, strength and toughness characteristics. It behaves well in forging and has excellent ductility and toughness in the annealed condition. Because of its low sensibility to notching effects and its excellent resistance to cavitations, Ti Gr.5 is suitable for any mechanical application and pressure vessels.
Chemical Composition (%) ASTM B348
Grade |
Carbon Max |
Oxygen Max |
Nitrogen Max |
Iron Max |
Hydrogen Max |
Aluminum Max |
Vanadium Max |
Grade5 |
0.08 |
0.20 |
0.05 |
0.40 |
0.015 |
5.5-6.75 |
3.5-4.5 |
Annealed Mechanical Properties ASTM B348
Grade |
Tensile Min |
Yield Min |
Elongation in 4D Min % |
Reduction of Area min % |
Grade 5 |
130Ksi (895Mpa) |
120Ksi (828Mpa) |
10 |
25 |
1. Supply Dimension
Products |
Size(mm) |
Condition |
Grade |
Specification |
Titanium bar/rods |
Diameter: 8.0—400mm Length: 500—4000mm |
Annealed |
GR1 GR2 GR3 GR5 GR7 GR9 GR12 TA5 GR23 Ti-6Al-4V 3M PT3V BT-9 VT1-0 |
GB/T2965-2007 GB/T13810 AMS 4928 ASTM B348 ASTMB381 ASTM F136 ASTMF67 |
Permissible variations in size for titanium bars-hot rolled round bar
Size(mm) |
Size Variations in (mm) |
· Ovality (max mm) |
9.52~11.11 |
±0.15 |
0.23 |
11.11~15.88 |
±0.17 |
0.25 |
15.88~22.23 |
±0.20 |
0.30 |
22.23~25.4 |
±0.22 |
0.33 |
25.4~28.58 |
±0.25 |
0.38 |
28.58~31.75 |
±0.27 |
0.40 |
31.75~34.93 |
±0.30 |
0.45 |
34.93~38.1 |
±0.35 |
0.53 |
38.1~50.8 |
±0.39 |
0.58 |
50.8~63.5 |
+0.79 |
0.58 |
63.5~88.9 |
+1.19 |
0.88 |
88.9~114.3 |
+1.58 |
1.16 |
114.3-139.7 |
+1.98 |
1.47 |
139.7—152.4 |
+3.17 |
1.77 |
2. Production process
Titanium Sponge----Compacting electrodes----Multiple melting-----Titanium ingots--- Machining---UT testing---Chemical composition inspection----Forged billets----Forged/Rolled---Annealed----Straightening----Machining----UT testing----Visual and Dimension Inspection---UT testing---Marking---Packaging
---Delivery
3. Application
1) Aerospace
2) Navigation & sea water desalination
3) Military
4) Medical
5) Chemical Industry & Petrochemical
6) Electrolysis & Electroplating
4. Quality Guarantee
(1) We have a Professional quality inspection team and advanced testing equipment.
(2) 100% Ultrasonic testing.
(3) Supply the third party chemical composition and mechanical property testing report.
5. Marking
According to clients requirements.
6. Packaging
In standard export wooden cases with reinforced each less 1000kgs.
