Product introduction
NARP pulse divider is high-voltage measuring systems with under-damping and potential shielding. Mainly used for measuring for light wave, including light full wave,8/20us wave and other light waveform. It’s a special voltage divider for light waveform. Simple to operate, intuitive display, high precision, small in size, light in weight. It’s ideal high-voltage measuring equipment for Grid primary equipment testing(such as Zinc oxide lightning arrester waves steep testing, voltage transformer lighting full-wave testing, high-voltage switch lighting fill-wave testing, substation main transformer testing, high-voltage GIS testing,etc.), substation, high-voltage electrical equipment factory and high-voltage testing laboratory and other relative departments.
Also called name
NARP Series pulse impulse divider, pulse divider
The Characteristics of the products
Adopting imported fill material and realizing highly stable, the inside adopt highly precision resistance and low tangent capacity, partial discharge. Small size, light weight, ans easy to take.
The parameters of the products
1, Voltage level: AC: 50 kV-2000kV (Able to withstand the impact of rates 110% voltage peak value )
2, Responding time:
3, Impact of voltage waveform:
Lightning impulse full wave (referred as to lightning full-wave lightning) the main parameters is peak UP, pre-wave time T1, half peak time T2, the pre-wave of standard lightning full-wave time is T1 = 1.2us
Half peak value time is T2 = 50us.
In order to obtain highly accurate testing data, it is recommended to adopt US Tektronix which more than 200M oscilloscope, while the other technical specifications should meet the high-voltage lightning wave measurement requirements.
4, Accuracy: AC: 3.0%
5, Insulating medium: Imported capacitor oil
6, Environmental conditions:
Temperature: 0℃ ~ 45 ℃
Humidity:
7, Divided voltage ratio: 1000:1 or (according to customer requirements)
Power supply: AC110V/115V/120V/127V/220V/230V/240V optional
Input frequency: 50Hz/60Hz optional
Note: Our users can select the corresponding power which based on their local supply voltage and frequency, and we will confirm it before the delivery (or inform us that the goods will be used in which country advance)
