H. 264 compression mode, real-time support 4 road 720 p millions AHD high-definition input, or four-way analog input sd cameras
9 v - 36 v adaptive wide voltage input, ultra low power design;
SD card storage (SD card can support 1 big capacity, maximum support 128 g) can be completely resist the car vibration dust and other cause data corruption;
Optional alarm input support 4 road, independent alarm output 1 road
Optional single RS232 serial port or single road RS485 extension
Support GPS/BD/G - SENSOR module extension;
Can implement remote the 3 g / 4 g (optional);
Support voice broadcast, intercom and text scheduling distributed function;Expansion of oil sensor, temperature sensor, inductor, LED advertising screen;(optional)
OTA equipment automatic upgrade function, can be automatically upgrade to version upgrades, maintenance more convenient
Support mobile phone remote monitoring and management, (optional)
High reliability air head joint, high cost performance, stable and reliable.
Product features
U HIS solution, h. 264 compression mode, more stream record, providing 720 p hd video effect.Support real-time 4 road 720 p millions AHD high-definition input / 4 road simulation sd camera input;
U live hd video recording, video 720 p / 960 h/D1 / HD1 / CIF optional, adjustable frame rate quality;
U professional car power design, 9-36 v dc wide voltage input;Overload, undervoltage, short circuit, reverse connection and so on the many kinds of protection circuit, suitable for all kinds of vehicles;
U provide 12 VDC / 2.5 Amp output power, for the camera, a small screen, and other peripheral equipment constant voltage power supply;
U SD card record data (can support 1 big capacity SD card, single card 128 g), was completely against the car vibration dust and so on lead to data corruption, make the product can meet most of the products can not adapt to bad road conditions;
U watchdog restart function abnormal protection, can better protect the machine and video;
U shut down time-lapse video recording can be set up to 90 minutes (time);
U automatic, manual, video recording, alarm video footage a variety of ways, to meet different needs;
U display record vehicle state, plates, lines, super-low speed and other vehicle information, convenient management;
U support GPS/BD, GSENSOR module extension (optional);
U can choose single RS232 serial port or single road RS485 extension;
U 4-8 way alarm input (doors, lights, steering, braking, reverse more various types can be configured), there are many kinds of response linkage;
U one way alarm output;
U high reliable air head video input/output interface, easy installation and pull plug, seismic performance is stronger;
U system interface is fluent, visual function, perfect;
U can through the SD card software upgrade;
U can be batch function to customize according to customer requirements;
U volume size and weight information:
U the machine size 147 mm (L) * 137 mm (W) * 37 m (H), 1 KG weight;
