Help CenterFANN VISCOMETER MODEL 35SA S/N 10095275 WORM GEAR 207963
Related Products
-
FANN INSTRUMENT VISCOMETER(V.G.METER) FANN MOD. 35,35A AND 35SA 30732US$ 10 - 12MOQ: 1 Piece -
BROOKS Instrument Pressure Regulators Model 8601US$ 220 - 250MOQ: 1 Piece
-
Brooks Mechanical Pressure Regulator Model 8601US$ 250 - 300MOQ: 1 Piece
-
FANN Resistivity Meter Model 88C 207960US$ 680 - 750MOQ: 1 Piece
-
FANN Instruments Model 35 Viscometer 207199 and 10095275NegotiableMOQ: 1 Piece
FANN VISCOMETER MODEL 35SA S/N 10095275 & 7, P/N 207199
Shenzhen PMZ Technology Inc is your good choice supplier to buy Varco top drive spare parts We supply ONLY GENUINE NEW petroleum, oil and gas, mineral, marine parts from North America and Europe.Fell free contact me info{at}pmztechnology{doc}com, skype Kate Lee_pmztechnology
Model 35 Viscometer
Viscometer Model 35Widely known as the Standard of the Industry for drilling fluid viscosity measurements
Fann produces a range of true Couette coaxial cylinder rotational viscometers. The Model 35 Viscometer is the best known and most commonly used Fann viscometer.
The test fluid is contained in the annular space or shear gap between the cylinders. Rotation of the outer cylinder at known velocities is accomplished through precision gearing. The viscous drag exerted by the fluid creates a torque on the inner cylinder or bob. This torque is transmitted to a precision spring where its deflection is measured and then related to the test conditions and instrument constants.
This system permits the true simulation of most significant flow process conditions encountered in industrial processing.
Direct Indicating Viscometers combine accuracy with simplicity of design, and are recommended for evaluating materials that are Bingham plastics. Model 35 Viscometers are equipped with factory installed R1 Rotor Sleeve, B1 Bob, F1 Torsion Spring, and a stainless steel sample cup for testing according to American Petroleum Institute Specification RP 13B.
Other rotor-bob combinations and/or torsion springs can be substituted to extend the torque measuring range or to increase the sensitivity of the torque measurement. Shear stress is read directly from a calibrated scale. Plastic viscosity and yield point of a fluid can be determined easily by making two simple subtractions from the observed data when the instrument is used with the R1-B1 combination and the standard F1 torsion spring.
A wide range of accessories are available for the Model 35 Viscometer.
The Model 35 Viscometer has been evaluated for compliance, and fulfills the requirements of EN 61010-1:2010, CAN/CSA C22.2 No. 61010-1-2012 and UL61010-2-030:2012.
A copy of this Declaration of Conformity is available upon request.
Ordering Information and Specifications
Six speed viscometers have speeds of 600, 300, 200, 100, 6, and 3 rpm
Twelve speed viscometers have speeds of 600, 300, 200, 180, 100, 90, 60, 30, 6, 3, 1.8, and 0.9 rpm
Part No. Model No. # of Speeds Voltage
207198 35A 6 115 Volts 60 HZ
207199 35SA 6 115 Volts 50 HZ
207200 35A/SR-12 12 115 Volts 60 HZ
207201 35SA/SR-12 12 115 Volts 50 HZ
101671767 35SA/SR-12 with Case and Transformer 12 115 Volts 50 HZ
101671768 35A with Case 6 115 Volts 60 HZ
101671770 35SA with Case and Transformer 6 115 Volts 50 HZ
101671771 35SA/SR-12 with Case 12 115 Volts 60 HZ
WORM GEAR 31771/207963
LOWER CHANGE GEAR 30917/207550
TEMP . WARNING TAG 31794/207971
BEARING ( COVER HOUSING) 30922/207555
SPEED SELECTION TAG 30795/207498
GEAR WORM 30716/207439
WASHER 30715/207438
BUSHING 30712/207436
SHAFT & GEAR FOR JACKSHAFT ASSY 30813/207507
SPACER 30701/207428
INTERNAL RETAINING RING 30026/207143
FLAT WASHER 31419/207817
MOTOR (35SA) 30725/207447
IDLER SHAFT 30976/207587
FLAT SHAFT 30776/207485
EXTERNAL RETAINER 31398/207814
IDLER GEAR( 35SA) 31919/208004
STRAIN RELIEF 31866/204371
POWER CORD A7003/203512
FANN old 331979 NEW 102365354 ROLLER OVEN MODEL 705ET 1000 WATT
FANN 102410859 VISCOMETER MODEL 45
FANN 210463 Oil & Water Retort Kit,
FANN RESISTIVITY METER MODEL 88C DIGITAL 207960 31763
MAIN SHAFT KEY 30804/207506
RETAINER (2) PART NO :31546/207867
BEARING SHIELD 30912/207546
CLAMP SLEEVE (2) 30986/207595
FANN VISCOMETER MODEL 35SA S/N 10095275 & 7,P/N207199 REF: FANN
DUST CAP PART NO :30973/207585
ROSSHILL 0100-0134-02 RHEOSTAT-1KOHM,DUAL ASSY F/HAND THROTTLE
DERRICK SQD-2510-MC03 HAND SWITCH STATER
DERRICK SQD-B770 FUSE HTR-4.69-5.18 AMPS
TEXENSE(TEXYS) SENSORS IRN2-C-420-mA-out
NOV 11445843-001 LOWER SEAL, LFS-3, 18-15M NXT/SLX
NOV 20083211 ACTUATOR, ROTARY, NO HELICAL GEAR, LH (MTO)
NOV 20083212 ACTUATOR, ROTARY, NO HELICAL GEAR, RH (MTO)
RETSCO 20805-02 SPRING LOAD RRV
MI SWACO VALVE HYD RELIEF DIRECT ACTING 1/2 FNPT 500-3000 PSI 5603230 replaces PN 5603225
MI SWACO GAUGE PRESS 0-10K PSI / 0-68K KPA 6 IN BM 1/4NPT 2422244
MI SWACO GAUGE POSITION INDICATOR 0-30 PSI OPEN CLOSE 9611143
MI SWACO METER ASSY DIGITAL STROKE RATE 2 PUMP 9611321
FANN VISCOMETER MODEL 35SA S/N:10095275 & 7,P/N207199
FANN COVER PLATE 39743/207459
FANN SPLASH GUARD 30887/207539
FANN SPLASH GUARD 30887/207539
FANN PLUG SCREW 3099/207603
DERRICK NYLOC NUT DERRICK NNLS-31-18-LT
DERRICK FLAT WASHER DERRICK WFSS-31
DERRICK FLAT HEAD SCREW DERRICK G0015322
DERRICK CARRIAGE BOLT DERRICK G0012710
DERRICK COMPRESSION ASSY DERRICK 19455-07
DERRICK COMPRESSION ASSY DERRICK G0015964
DERRICK COMPRESSION ASSY DERRICK G0015963
DERRICK COMPRESSION SIDE PIN ASSEMBLY
DERRICK ACTUATOR DERRICK 19346-01
DERRICK STIFFENER PLATE DERRICK 19455-04
DERRICK STIFFENER PLATE DERRICK 19455-07
DERRICK STRAIGHT PAWL DERRICK 19341-23
DERRICK BENT PAWL DERRICK 19341-22
DERRICK REPLACEABLE FIXED PIN ASSEMBLY DERRICK
DERRICK CYCLONE ASSY 4in DERRICK 10523-12
FANN model 140 mud balance 206768
FANN model 141 TRU-WATE Pressuerized Balance 100003565
FANN model 140 mud balance without case 206769
KOOMEY ACCUMULATOR TYPE 80 MODEL:2000-11 SX SER.NO.4227 AIR OPERATED PUMP 60:1 RAITO 8-1/2 IN.DIA.AIR MOTOR PART NO.3012-2100 AIR MOTOR 8-1/2 DIA.
KOOMEY 3012-2199 REPAIR KIT
KOOMEY 3033-0199 FLUID END REPAIR KIT
KOOMEY 3023-0100 AIR MOTOR-8 1/2
KOOMEY 1110-2100 REGULATOR VALVE
