2015 new design high precision micro filtre maille metallique
We are professional in high precision filter mesh for 8 years and welcome custom design, Please send us an inquiry for more details, we will do our best to help.
Process Capability | |
The Min. Size |
0.039“*0.039” (1mm*1mm) |
The Max. Size |
27.56“*23.62” (700mm*600mm) |
Thickness |
0.0012"-0.059" (0.03mm-1.5mm) |
Thickness Tolerance |
+/-0.0002" (+/-0.005mm) |
The Min. Opening precision |
Φ 0.0008" (Φ 0.02mm) |
The smallest diameter |
0.0004" (0.01mm) |
Dimension Tolerance |
+/-0.0003" (+/-0.008mm) |
Elastic line tolerances |
+/-0.0002" (+/-0.005mm) |
The shallowest depth |
0.0004" (0.01mm) |
Depth accuracy tolerance |
+/-0.0002" (+/-0.005mm) |
Special Technique |
Second on the bit, No connection point,etching and stamping |
Below are the some standards on hole,but Custom design is welcome.
| Part No. | Thick.(inch) | A hole size | Tolerance | B on-center | Open% |
| 2-5-01 | 0.002 | 0.005 | +/-0.001 | 0.008 | 35% |
| 2-11-02s | 0.002 | 0.011 | +/-0.001 | 0.014 | 60% |
| 2-20-03s | 0.002 | 0.02 | +/-0.001 | 0.023 | 80% |
| 2-33-04s | 0.002 | 0.033 | +/-0.001 | 0.042 | 60% |
| 4-6-01 | 0.004 | 0.006 | +/-0.001 | 0.01 | 15% |
| 5-7-01 | 0.004 | 0.007 | +/-0.001 | 0.012 | 17% |
| 5-11-02 | 0.005 | 0.011 | +/-0.001 | 0.017 | 38% |
| 8-9-01 | 0.008 | 0.009 | +/-0.0015 | 0.0155 | 31% |
| 8-9-02** | 0.008 | 0.009 | +/-0.0015 | 0.0155 | 31% |
| 8-12-03 | 0.008 | 0.012 | +/-0.0015 | 0.018 | 40% |
| 10-13-01 | 0.01 | 0.013 | +/-0.0015 | 0.02 | 38% |
| 10-15-02 | 0.01 | 0.015 | +/-0.0015 | 0.025 | 28% |
| 15-20-01 | 0.015 | 0.02 | +/-0.002 | 0.035 | 30% |
| 15-50-02 | 0.015 | 0.05 | +/-0.002 | 0.075 | 40% |
| 15-25-03 | 0.015 | 0.025 | +/-0.002 | 0.044 | 25% |
| 18-20-01** | 0.018 | 0.018 | +/-0.002 | 0.035 | 25% |
| 25-33-01** | 0.025 | 0.025 | +/-0.003 | 0.055 | 28% |
Product Details:
2015 new design high precision micro filtre maille metallique
Product Description | |
Product name: |
micro filtre maille metallique |
Material: |
Stainless steel or customized |
Size: |
18cm*18cm |
Thickness: |
0.1mm |
Technique: |
High precision etching |
Hole: |
0.01mm |
Spacing |
0.018mm |
Hole shape: |
Round |
Surface: |
Polished |
Features: |
No burrs,No broken point,no plugging holes |
Application: |
Fiber filter,Textile machines |
Certificate: |
RoHS,ISO |
Inspection: |
Two-dimension inspection machine,magnifier |
Other Related Items | |
Price: |
According to product specification |
Sample Offer: |
Within 3-6 days |
Payment: |
T/T,L/C,D/P,Paypal,Western Union |
Lead time for mass production: |
Within 6-10 days after PI confirmed |
Production ability: |
10000pcs/day |
Metal process methods available: |
Stamping,Chemical etching,Laser cutting |
Acceptable file format: |
DWG,DXF,IGES,PDF,JEPG |
| standard met: | Customer specification,2D CAD drawing |
Packaging and Shipping:
Packaging Detail:
1.Paper in the fist layer
2.Plastic bags on the second layer
3.Carton
4.Wooden case outside
Time for shipment: Samples within 3-5 days,mass production within 6-10 days
Company Information:
Shenzhen Xinhaisen Technology Ltd.
We are a leading Manufacturer handling in Chemical Etching for 8 years, adhere to do business on the basis of WIN-WIN and pay much attention to quality and cost control.
Products: EMI/RF shield, Precision metal mesh, Encoder disc, VCM spacer, Foot file, metal shims, Metal cards, arts and crafts, logo, sign, some other etched things, Etc.
Our Advantages:
1. Low cost for sampling of this metal filter mesh with competitive price
2. Advanced & Standardization workshops and facilitates.
3. High-tech and high precision manufacturing equipment.
4. Strict ISO14001:2004 , ISO9001:2008 standards.
5. ROHS compliant & enviroment friendly products.
6. Professional technical specialists and management personel
7. 100% in house inspection before delivery
8. All OEM/EDM is welcomed
Our Service:
1,Your inquiry related to our products or prices will be replied in 12 hours
2,We will do our best to meet all kinds of your demands
4,Fast sampling,fast shipping,fast communication
5,Quality control are strictly according to ROHS,ISO and our own standard
6,Stable output and prompt delivery
7,Distributorship are offered for your unique design and some our current models
8,Protection of your sales area,ideas of design and all your private information
Any comments about our Metal filter mesh will be highly appreciated, please feel free to send us the inquiry, We will do our best to help.
Rick Fan
Shenzhen Xinhaisen Technology Limited
(Tel): (+)86 755 29791052
(Fax): (+)86 755 29791571
(mobile):18607107431
E-mail: Rick(at)xinhsen(dot)com
Skype: Rick(at)xinhsen(dot)com
2015 new design high precision micro filtre maille metallique
