FE220.8 construction machinery for earthmoving
Model | FE210.8 | FE220.8 | FE240.8 | FE360.8 |
Weight | 20.9 | 21.6 | 23.6 | 34.1 |
Bucket capacity(m3) | 0.8-0.93 | 0.9-1.05 | 1-1.2 | 1.6 |
Engine Model | CUMMINS B5.9-C | CUMMINS B5.9-C | CUMMINS B5.9-C | CUMMINS 6CTAA8.3 |
Power(kw/r/min) | 112/1950 | 112/1950 | 133/2000 | 198/2000 |
Fuel Tank capacity(L) | 350 | 350 | 350 | 595 |
Tracking speed(km/h) | 5.2/3.5 | 5.2/3.5 | 5.2/3.5 | 5.2/3.3 |
turing speed(r/min) | 11.7 | 11.1 | 11.1 | 10.6 |
Climbing ability(%) | 70 | 70 | 70 | 70 |
bucket digging force(KN) ISO | 145 | 145 | 159 | 208 |
Ground Pressure(KPa) | 46.5 | 48.6 | 48.6 | 68.3 |
Hydraulic Pump Model | K3V112DT | K3V112DT | K3V112DT | K3V140DT |
Maximum Flow（L/min) | 200*2 | 226*2 | 226*2 | 265*2 |
Operation Pressure(MPa) | 34.3 | 34.3 | 34.3 | 34.3 |
Oil Tank Capacity(L) | 246 | 246 | 246 | 310 |
A-Overall Length(mm) | 9390 | 9740 | 9740 | 11260 |
B-Overall Width(mm) | 2800 | 2980 | 2980 | 2995 |
C-Overall Height(Arm top)(mm) | 3040 | 3190 | 3190 | 3180 |
D-Overall Hight(CAB top)(mm) | 3060 | 3120 | 3120 | 3280 |
E-Loading Weight distance from ground(mm) | 1100 | 1065 | 1065 | 1210 |
F-Minimum Distance (mm) | 468 | 442 | 442 | 498 |
G-End turning radius(mm) | 2720 | 2810 | 2810 | 3600 |
H-Track shoe length on ground(mm) | 3445 | 3640 | 3640 | 3700 |
J-track shoe assy length(mm) | 4260 | 4450 | 4450 | 4622 |
K-track distance(mm) | 2180 | 2380 | 2380 | 2590 |
L-track shoe assy width(mm) | 2800 | 2980 | 2980 | 3190 |
M-track shoe wideth(mm) | 600 | 600 | 600 | 600 |
N-turning platform width(mm) | 2700 | 2700 | 2700 | 2995 |
O-Maximum digging height(mm) | 9275 | 9310 | 9310 | 10200 |
P-Maximum unLoading Height(mm) | 6560 | 6440 | 6440 | 7135 |
Q-Maximum digging depth(mm) | 6515 | 6875 | 6875 | 7370 |
R-Maxium Vertical digging depth(mm) | 5000 | 5860 | 5860 | 6380 |
S-Maximum digging depth for transverse plane 2.5 m (mm) | 6650 | 6680 | 6680 | 7190 |
T-Maximum digging distance | 9865 | 10170 | 10170 | 11100 |
U-Maximum digging distance at horizontal plane(mm) | 9680 | 9990 | 9990 | 10910 |
V-Minimum Turning Radius(mm) | 3630 | 3975 | 3975 | 4265 |
W-Maximum height at minimum turning radius.(mm) | 7670 | 7775 | 7775 | 8500 |
X-The distance from turning center to back tail end(mm) | 2720 | 2810 | 2810 | 3600 |
Z-Load weight height(mm) | 2120 | 2120 | 2120 | 2265 |
A1-Ground distance(On transportation)(mm) | 4840 | 5164 | 5165 | 5720 |
Bucket dipper distance (mm) | 2900 | 3050 | 3050 | 3185 |
Arm length(mm) | 5700 | 5850 | 5850 | 6470 |
Note: the excavator developed and new parameters will be upgraded accordingly, all the parameters are on the real machine. | ||||
