U Type Box Assembly Machine
Box Beam Production Line
Steel Structure Production Line
The automation control is fulfilled in the production process of heavy duty beam vertical assembly machine. The process steps of clamping, alignment, positioning and automatic spot welding for flange plate and web plate are controlled by Japanese Mitsubishi programmable logic controller and AC frequency converter. Thus, the efficiency of the equipment is more than two times of ordinary assembly machine. This kind of equipment of our company has the merits of working stably and reliably. Equipped with tracking arc-guide mechanism, the welding gun can assure the quality of spot welding.
Specification
Length of work-piece |
4000-15000mm |
Thickness of wprk-piece |
20-80mm |
Max loading capacity |
20t |
Frame moving speed |
4/6m/min |
Hydraulic system pressure |
14MPa |
Left-right oil cylinder max working pressure |
15t |
Up oil cylinder max pressure |
30t |
Left-right oil cylinder max stroke |
800mm |
Up oil cylinder max stroke |
900mm |
Moving motor power |
0.85/1.1kw×2 |
Pump station motor power |
11kw |
Roller conveyor motor power(single machine no roller conveyou) |
2.2kw |
Roller conveyor conveying speed |
9.3m/min |
Above are our standard model,it can be designed and manufactured according to customer’s request | |
