Company profile:
Shanghai BOGU have established a whole production chain, of which main products cover truck scales, portable truck scale, permanent truck scale,truck trailer scales, vehicle weighing systems, Weighbridges10ton/20ton/30ton/40ton/50ton/60ton/80ton/100ton/120ton/150ton/200ton and so on. They are widely used in the industry of mining, construction chemicals, metallurgy, transportation, factories, food ,logistics and so on. Our products are not only renowned in more than 20 provinces and cities in domestic markets, but also have being sold popularly in more than 120 countries and areas all over the world like Eastern Europe, Middle East, Africa, South Asia, Southeast Asia, Oceania, and Central and South America etc.
Product profiel
Capability (Single Axle) | 5T | 10T | 15T | 20T | 30T | |
Pad Dimension | 700*430*10(mm) | 800*430*10(mm) | ||||
Ramp Dimension | 700*350(mm) | 800*350(mm) | ||||
Precision | Static±0.05%, Dynastic±2% | |||||
Load Cell Structure | Pad is load cell, strain gauge inside | |||||
Cable Length | One set include 2 weighing pads, Cable length is 10m and 8m, but longer cable is optional. | |||||
Division | 0.5kg, 1kg, 2kg, 5kg, 10kg, 20kg, 50kg | |||||
Inspecting Speed | ≦10km/h on average | |||||
Work Temperature | ﹣45℃ ~ ﹢70℃ | |||||
Advantages:
l The unique structure design of key components accepts the weigh to be 120% more than weighing capability.
l It contributes huge work in transportation, construction and Highways enforcement, etc.
l It would be the only choice to replace truck scale for monitoring some special vehicles’ load.
l Multiple seal protection and water proof for the system to work in raining or snowing.
l The pad adopts IP866 ~ IP67 protection level, even better sealing for harsh environments.
l According to different situation, you can chose different working modes: Traffic police mode, highways mode and ministries mode.
