Help CenterGrinding Mill
US$ 5000 - 10000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Shuguang
Place of Origin:
China
Model Number:
Grinding Mill
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao,Tianjin or others port
Delivery Detail:
30 days
Related Products
Brand Name
Shuguang
Place of Origin
China
Model Number
Grinding Mill
Type
Raymond Mill
Certification
ISO,CE
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
12 months
Weight
1.5 - 14T
Dimension(L*W*H)
Grinding Mill
Condition
New
Motor Type
AC Motor
Capacity(t/h)
2-8 T/H
Grinding Mill has been widely used in the processing of non-metallic minerals. But the application of nonmetallic minerals in the ultrafine powder of extensive development, downstream enterprises more and more high to the requirement of non-metallic minerals, especially for product fineness had the higher request, make the traditional Grinding Mill ragged. For our traditional Grinding machine is carried on the thorough analysis and research, to solve the traditional Grinding Mill of frequent maintenance and high maintenance cost, Grinding fineness is not up to standard, and many other fatal defects, and developed a set of crushing, Grinding, greatly enhanced in the integration of new type superfine Grinding Mill. Because of its high efficiency, low energy consumption, greatly enhanced, cover an area of an area small, less investment and environmental pollution-free advantages and are widely used in metallurgy, building materials, chemical industry, mines and other minerals in the field of grinding materials processing, suitable for processing mohs hardness under seven, humidity under 6% of all kinds of inflammable and explosive minerals, such as gypsum, talc, calcite, limestone, marble, potassium feldspar, barite, dolomite, granite, kaolin, bentonite, medical stone, bauxite, iron oxide red, iron ore, etc.
Detailed Data
Type |
6R4525 |
5R4121 |
5R4119 |
4R3218 |
4R3216 |
Max feeding size(mm) |
30 |
30 |
25 |
30 |
30 |
Fineness of finished product(mm) |
0.125-0.044 |
0.125-0.044 |
0.125-0.044 |
0.125-0.044 |
0.125-0.044 |
Production(t) |
13-40 |
8-15 |
5-10 |
2.5-9 |
2-8 |
Speed of axis(r/min) |
82 |
105 |
105 |
130 |
130 |
Diameter of Ring (mm) |
1620 |
1270 |
1270 |
970 |
970 |
Diameter of Roller(mm) |
450 |
410 |
410 |
320 |
320 |
Roller height(mm) |
250 |
210 |
190 |
180 |
160 |
Main motor (KW) |
Y315m-4-132 |
Y280s-4-75 |
Y280s-4-75 |
Y225s-4-37 |
Y225s-4-37 |
Fan motor (KW) |
Y315m-4-132 |
Y250m-4-75 |
Y250m-4-75 |
Y200L-4-37 |
Y200L-4-37 |
Analysis motor(KW) |
Y160m-4-11 |
Yc200-4-7.5 |
Yc200-4-7.5 |
Yc120-4-5.5 |
Yc120-4-5.5 |
