Ingke YKG-832409NL 100% cross XMH-9760-JL7D130-886 2x4 Ports RJ45 Jacks With Magnetics

Ingke YKG-832409NL 100% cross XMH-9760-JL7D130-886 2x4 Ports RJ45 Jacks With Magnetics

Part Number : XMH-9760-JL7D130-886

Made in China:YKG-832409NL

Original Manufacturer:Ingke Technology

Supply Ability:5500K-PCS/Month

Product Category: Modular Connectors / Ethernet Connectors

Packaging :Tray

Connector Type: RJ45

Number of Ports :8

Number of Rows :2

Applications : 10/100/1000Base-T, AutoMDIX

Mounting Type : Through Hole

Orientation:  90° Angle (Right)

Termination :Solder

LED Color: Green,Yellow-Green,Yellow

Number of Cores per Jack : 8

Shielding : Shielded, EMI Finger

Features: Board Guide

Tab Direction : Up and Down

Contact Material : Copper Alloy

Contact Finish : Gold

Operating Temperature : -40℃~85℃

Flammability Rating: UL 94 V-0

Contact Finish Thickness : 30µin (0.76µm)

Shield Material : Copper Alloy

Housing Material : Thermoplastic

Manufacturer: Ingke Technology Co.,Ltd

Our service:

 1).Free sample is available!

 2).OEM & ODM orders are welcomed.

 3).We offer after-sale service for 8 years.

Our Advantage:

 (1).OEM factory for Connector more than 10 years.

 (2).Cost reduction, lead time within 1 week, FREE samples.

(3).After sales services 24*7 to help you solve any kind of problems

(4).Factory in central province of China, the products has been improved in Mechanical properties, electrical properties and environmental performance for 10-15%,moreover the price are more competitive for 5-10% over the market

(5).Main advantage products: 10G ICM and M8 connector(Vendor of ST and Qualcomm)

Ingke Technology Mass production of the following models;

XMH-845-2622 XMH-TRJG-22747A4NL XMH-859G828-2223C12 XMH-TRJG27561AENL XMH-TRJG27849CNL XMH-9766-8813-4-S3LX-Z XMH-24T-398-A62-012-D XMH-2464D3002 XMH-TRJG47542AHNL XMH-T15-041-A62-013 XMH-JDHC211NDC XMH-B59G856-4625C12 XMH-YL5917222X4PLE XMH-YL5917232X4LE XMH-YL5917232X4LE-3 XMH-99TF-0320840023107 XMH-99TD-H5C08570225 XMH-EH-26E-4-H62-170 XMH-260040-6400 XMH-2696U3009-2 XMH-T16-071-A62-013 XMH-TRJG-67537CNL XMH-YL5917222X6PLE XMH-B59G810-8623C12
