Full HD 1080P C Band LNBF Input 3.4-4.2Ghz lnb c band waterproof
Key Features:1. Higher conversion gain
2. Ultimate reliability
3. Superior noise figure
4. Waterproof, weather protection, high performance
5. Easy installation
6. OEM&ODM supported
7. Low power consumption
Brands We Served:
Product Description :
Specifications:
|
1.Input Frequency: 3.4 to 4.2GHz 2. L.O. Frequency:5150MHz(±500 MHz@25) 3.Output Frequency:950 to 1750 MHz 4.L.O. Leakage Input Port: 45dBm 5.L.O. Stability: ±1.5MHz(-40to+70) 6.Noise Figure:17°K typ 7.Conversion Gain:>65dB type |
8.gain Flatness:±1 dBm(max)
9.Intput VSWR:2.5:1(max)
10.Output VSWR:2.0:1(max)
11.Output Connector:F-female Connector
12.Output Impedance:75Ω
13.Cross Polar Isolation:20dB(min)
14.Image Rejection:45 dB (min)
15.Phase Noise:-75dBc/Hz@10kHz(max)
16.Supply Voltage:
1)11.5-14.0v(Vertical Polarization)
2)16.0-19.0v(Horizontal Polarization)
17.Operating Temperature:-40to+70
18.Storage Temperature:-40to+80
19.Relative Humidity:0%-95%
Why us? company info
Anhui Bowei Electronic Technology Co., Ltd is aspecialist company for manufacturing and selling all kinds of microwave high frequency electronics including Yagi antenna, satellite antenna, LNB etc. for more than 20 years. We are always emphasizing " quality is our culture". It is our responsibility to provide clients with high quality and low price goods. Factory producing process:
Production line- Assembly- Gluing lnbf caps- waterproof & sealing- Testing before packing
Shipping:
We do our best to process your order as quickly as possible. Related Products: |
We are professional manufacturer of lnbf and electronics products in China more than 20 years
Welcome to contact with us for more details!
|
