24" Vinyl Cutter W/Contour Cutting

24" Vinyl Cutter W/Contour Cutting photo-1
24" Vinyl Cutter W/Contour Cutting photo-2
24" Vinyl Cutter W/Contour Cutting photo-3
24" Vinyl Cutter W/Contour Cutting photo-4
US$ 223.88 - 250.75 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
MIRACLE
Model Number:
MI-CP01
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name MIRACLE
Model Number MI-CP01
Voltage AC220V/110V,50Hz-60Hz
Paper Feed Width 630mm
Cutting Width 710mm/2.33ft
Cutting Speed 800mm/s
Driver flexi auto mark
Size 24"



Product Description

 1,Rael Contour cut function,full-automatic and easy to achieve contour cut without interference from other light sources,high resolution.

 2,New adopted ARM processor and new driver module,system more powerful,driving more stable.
 3,USB 2.0 interface, support hot-swappable, and is equipped with serial port to support the long-distance data transmission.Besides,it supports U disk direct reading function,convenient and fast.
 4,1Gb super-memory achieves a long time Offline cutting, meanwhile, the data storage can be achieved even blackout.
 5,New high-speed STM32 remote control system, higher speed, lower noise.
 6,Digital force & speed adjustable, direct and steady.
 7,Humane design, allows to adjust cutting force and speed while working.
 8,High-precision "steel barbed" axis, higher accuracy.
 9,Auto. memory of blade force & Speed, adjustable at any time, easy to use.
 10,Emergency stop & stop to return at any time to monitor the cutting quality, easy to operate.
 11,Bulk copy up to 99, saving time and strength.



Data Specifications:
Model       MI-CP01
Cutting Size              630mm/2.07ft                               800mm/2.62ft                           1260mm/4.13ft

Media Size       710mm/2.33ft                  880mm/2.89ft                1340mm/4.40ft

Cutting Speed                                                                       800mm/s
Cutting Pressure                                                     1-800g Digital adjustable
LCD Display               Yes                                                       Yes                                                 Yes
Buffer capacity                                                              1GB - Recyclable.
Resolution                                                                       0.0254mm/step
Offset                                                                                      0-1mm/m
Origin Adjustable                                                                        Yes
Repeatability                                                                            0.127mm
Power                                <100W                                                   AC220V(110V)±15% ,<160W
Language Format                                                           HP-GL,DM-PL
Interface Serial Port&                                                             USB2.0
Drive                                                                                   Step Motor
Princh Roller                                               3pcs                                                                      4pcs

Specifications are subject to change without prior notice.
