Nonferrous Mineral Ores Sintering Rotary Kiln Furnace
- 30000 Ton / Tons per Month
- Shanghai
- T/T L/C D/P D/A
- 150 days
- 1500-12000 Tpd Cement (Clinker production) Plant
- Cement Mill for 3000-7000 Tpd Clinker Production Line Factory
- Ball Mill for Cement Clinker and Stone Crushing Grinding Plant
- Roller Press Machine for 1000-8000 Tpd Cement Clinker Grinding Plant Unit
- Calcium Carbonate Superfine Grinding Mill / Sand Ball Grinding Mill
- Vertical Roller Mill for 2500-9000 Tpd Cement Manufacfturing Plant Project
Product Details
Brand Name: | Pengfei | Place of Origin: | China | Model Number: | PF-16 |
Type: | Other, Rotary kiln | Certification: | ISO 9001, CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Warranty: | one years | Weight: | Undetermined | Dimension(L*W*H): | Undetermined |
Voltage: | 380V | Usage: | Sintering Furnace | Condition: | New |
Power(W): | Undetermined |
Product Description
Description of Lateritic Nickel Rotary Kiln:
Our lateritic nickel rotary kiln is mainly used to smelt lateritic nickel ores so as so get nickel pig iron. So far Jiangsu Pengfei Group Co., Ltd has successfully carried out many projects in China, such as Guangqing in Guangdong Province, Dingxin in Fujian Province, Qingshan in Zhejiang Province, Linyi in Shandong Province, and more.
Technological Parameters of Φ5.2×118m Y52118 Series Lateritic Nickel Rotary Kiln:
1. Application: Roasting of 1950-2200t/d lateritic nickel ores
2. Specification: Φ5.2×118m (inner diameter of cylinder×length)
3. Type: Double-driving, double hydraulic thrust rollers
4. Kiln supporting: 5
5. Slope: 3.5%
6. Rotating speed: main driving: 0.2 ~1.233r/min; auxiliary driving: 7.82r/h
7. Sealing mode: Flexible sealing
8. Kiln head cooling: air cooling
9. Main driving motor:
Amount: 2 sets
Model: YSNP450L1-6
Power: 355×2 kW
Voltage: 380V
Rotating speed: 980r/min
10. Main speed reducer:
Model: P320-90Ⅴ/Ⅵ
Width between centers: 1650
Velocity ratio: 90/92.273
11. Auxiliary driving motor:
Amount: 2 sets
Model: Y225S-4
Power: 37 kW
Voltage: 380V AC
Rotating speed: 1480r/min
12. Auxiliary driving reducer:
Amount: 2 sets
Model: YNL305-14Ⅰ/Ⅱ
Width between centers: 305 mm
Speed ratio: 14/14.291
Pengfei Group is one of the professional lateritic nickel rotary kiln manufacturers and suppliers in China. Our factory can offer you low price but quality, newest and advanced products made in China. We are one of the most famous such brands. Welcome to buy our customized, durable and easy-maintainable lateritic nickel rotary kiln and also welcome to check the quotation with us.
Established in 1994, Jiangsu Pengfei Group Co., Ltd is a professional manufacturer of ф6.2×87m rotary kiln in China. Besidesф6.2×87m rotary kiln, we also provide customers worldwide with metallurgy rotary kiln, lateritic nickel rotary kiln, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. With the certification of ISO9000 and CE, our products have been well received by customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Iran, Japan, South Korea, Bengal, Pakistan, Turkey, Vietnam, South Africa, Columbia, Bolivia, etc. If you're interested in our ф6.2×87m rotary kiln, please contact us freely.
Contact Us
- Jiangsu Pengfei Group Co., Ltd.
- Contact nameJerry Liu
- Phone86-139-62702248
- AddressBenjia ji, northern suburb of Haian county Nantong,Jiangsu
