Help CenterCNC Grinding Wheel For CNC Tool Grinder
Related Products
-
Diamond Bruting Wheel Bruting Natural DiamondUS$ 1 - 100MOQ: 1 Piece -
Resin Diamond Grinding Wheel For Thermal Spray CoatingUS$ 1 - 100MOQ: 1 Piece
-
Vitrified/resin Centerless Diamond Grinding WheelUS$ 1 - 100MOQ: 1 Piece
-
CBN Diamond Grinding Wheels For Woodworking ToolsUS$ 1 - 100MOQ: 1 Piece
-
Roller Dress Grinding WheelNegotiableMOQ: 1 Piece
More SuperHard Diamond / CBN Grinding Wheel For CNC Tool Grinder Is Used For Tungsten Carbide, High Speed Steel (HSS), Stainless Drill ,End Mill And Reamer.
We Will Provide A Complete Solution For CNC Tools Manufacturing Process, Including Fluting, Gashing And Clear Edge, Relief Angle Grinding .
| Fluting : Perfect Flute Surface Quality; Extremely High Stock Removal; Very Low Energy Consumption | |||||
| Model | D (Mm) | T (Mm) | X (Mm) | H (Mm) | Grit |
|
1A1 |
75 | 10 | 5 | 20 | D64 |
| 100 | 6, 10, 12 | 5, 10 | 20 | D46, D64 | |
| 125 | 10, 12, 16 | 10 | 20 | D46, D64 | |
| 150 | 12 | 10 | 20 | D64 | |
|
1V1 |
D (Mm) | T (Mm) | X (Mm) | H (Mm) | V° |
| 75 | 10 | 5 | 20 | 45 | |
| 100 | 10， 15 | 5 | 20 | 45 | |
| 125 | 6， 10， 15 | 5 | 20 | 45 | |
| 150 | 12 | 5 | 20 | 45 | |
|
14F1 ( Flute For Drill ) |
D (Mm) | U (Mm) | X (Mm) | H (Mm) |
R |
| 100 | 4 | 6 | 20 | 2 | |
| 125 | 3 | 5 | 20 | 1.5 | |
| 150 | 1,5 | 5, 7 | 20 | 0.5 , 2.5 | |
| Gashing And Clear Edge:The Production Of Superior Tool Edge Quality ;High Stock Removal; Maintaining Wheel Profile | |||||
| Model | D (Mm) | T (Mm) | X (Mm) | H (Mm) | V° |
|
1V1 |
100 | 10, 15 | 5, 10 | 20 | 45 |
| 125 | 4, 10, 15 | 5, 6, 10 | 20 | 45 | |
|
12V9 |
D (Mm) | W (Mm) | X (Mm) | H (Mm) | |
| 75 | 3 | 10 | 20 | ||
| 100 |
3 | 10 | 20 | ||
| 125 | 3 | 10 | 20 | ||
| 150 | 3 | 10 | 20 | ||
| Relief Angle Grinding: Excellent Surface Finish And The Best Profile Consistency;Excellent Edge Quality ;High Stock Removal At Second Relief | |||||
|
12V9 |
D (Mm) | W (Mm) | X (Mm) | H (Mm) | |
| 75 |
3 | 10 | 20 | ||
| 100 | 2, 3 | 10 | 20 | ||
| 125 | 3 | 10 | 20 | ||
| Other Specification Can Be Made According To Customers Requirements. Email: @Moresuperhard.Com | |||||
CNC Tools Grinder: Walter, ANCA, EWAG, Farman, Schutte, Schneeberger, Makino, Stuer, Strausak, Cininnati, Griffo, Huffmann, Jungner, CUOGHI, Fehlmann And So On.
Meanwhile, More Superhard Products Co,.Ltd Also Supplies Diamond Cutting Disc For Carbide Rods Cutting; Centerless Grinding Wheel For Carbide Bars; Silicon Carbide Wheel For Dressing CNC Grinding Wheel (Dressing Machines: Cleveland , Farman) And So On.
