LD199E Explosion Proof Digital Pressure Gauge 68mm LCD Display Battery Powered
LD199E explosion proof digital pressure gauge is battery powered pressure gauge used for liquid, gas that compatible with stainless steel . It can be used for portable equipment, no power source site.
Features:
LCD display, high solution ratio, no apparent value error.
Peak holding: it can record the max pressure value in the measuring process.
Percentage Dynamic display
Pressure units: psi, bar, kpa, kg/cm3, Mpa
Auto power-off function: 1~15 mins optional.
Low power consumption: continuous working: 2000 hours. Power save mode: it can work 2 years.
Sample rate: 4times/second.
Specifications
Dial size: |
62mm (LD198), 68mm(LD199E) |
Display: |
LCD |
Display range: |
-1999~9999 |
Accuracy: |
0.2%FS, 0.5%FS |
Pressure range: |
0-100Mpa |
Overload: |
200% |
Power supply: |
Battery, 9 VDC |
Stability: |
≤0.1%/year |
Ambient temperature: |
-20~70°C |
Relative humidity: |
≤80% |
ordering guide
LD199E |
68mm, radial, battery powered (9VDC), explosion proof |
||||
Accuracy |
2 |
0.2%FS |
|||
5 |
0.5% FS |
||||
Process connection |
G2 |
G1/2 |
|||
G5 |
G1/4 |
||||
M2 |
M20*1.5 |
||||
XX |
Others such as flange, probe, etc. please specify when enquiry and ordering |
||||
Pressure range |
*** |
0-100Mpa |
|||
