BMR Hydraulic Motor

BMR Hydraulic Motor thumbnail-1
BMR Hydraulic Motor photo-1
US$ 55 - 60 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Hanjiu
Place of Origin:
China
Model Number:
BMR
Contact Supplier Request Quote Chat Now
Shijiazhuang Hanjiu Technology Co.,Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Hanjiu
Place of Origin China
Model Number BMR
Type Hydraulic Motors

Hydraulic Orbit Motor BMR



BMR series motor adapt the advanced Gerolor gear set design with shaft distribution flow, which can automatically compensate in operating with high pressure , provide reliable and smooth operation, high efficiency and long life.
Characteristic Features:
   *Advanced manufacturing devices for the Gerolor gear set, which use low pressure of start-up, provide smooth, reliable operation and high efficiency.
   *Shaft seal can bear high pressure of back and the motor can be used in parallel or in series.
   *Special design in the driver-linker and prolong operating life
   *Special design for distribution system can meet the requirement of low noise of unit.
   *Compact volume and easy installation.


Order Code:

 Code

BMR

 Displacement

36
50
80
100
125
160
200
250
315
375

 Flange

2

2-Ø13.5 Rhomb-flange,pilot Ø82.5×8

4

4-Ø13.5 Rhomb-flange,pilot Ø82.5×8

H4

4-3/8-16 Square-flange,pilot Ø44.4×2.8

H5

4-M10 Square-flange,pilot Ø44.4×2.8

 Output Shaft

A

Shaft Ø25,parallel Key 8x7x32

B

Shaft Ø32,parallel Key 10x8x45

C

Shaft Ø25.4,parallel Key 6.35x6.35x31.75

E

Shaft Ø25.4,splined tooth SAE 6B

R

Short shaft Ø25.4,parallel key 6.35x6.35x31.75

F

Shaft Ø31.75,splined tooth 14-DP12/24

FD

Long shaft Ø31.75,splined tooth 14-DP12/24

G

Shaft Ø31.75,parallel Key 7.96x7.96x31.75

T

Cone-Shaft Ø28.56,parallel Key B5x5x14

 Port and Drain Port

D

G1/2 Manifold Mount 4-M8, G1/4

M

M22×1.5 Manifold Mount 4-M8, M14×1.5

S

7/8-14 O-ring manifold 4-5/16-18UNC, 7/16-20UNF

P

1/2-14 NPTF Manifold 4-5/16-18UNC,7/16-20UNF

R

PT(Rc)1/2 Manifold 4-M8, PT(Rc)1/4

 Rotation Direction

Omit

Standard

R

Opposite

 Paint

00

No paint

Omit

Blue

B

Black

S

Silver grey

 Unusually Function

Omit

Standard

N

Big radial force

O

No case drain

F

Free Running

LS

Low Speed


Main Specifications:

Technical data for BMR with 25 and 1 in and 1 in splined and 28.56 tapered shaft:

TypeBMRBMRS36BMRBMRS50BMRBMRS80BMRBMRS100BMRBMRS125BMRBMRS160BMRBMRS200BMRBMRS250BMRBMRS315BMRBMRS375Geometric displacement (cm3 /rev.)3651.781.5102127.2157.2194.5253.3317.5381.4Max. speed  (rpm)cont.1085960750600475378310240190155int.12201150940750600475385300240190Max. torque  (N·m)cont.72100195240300360360390390365int.83126220280340430440490535495peak105165270320370460560640650680Max. output   (kW)cont.8.59.512.51312.512.510765int.9.811.2151514.514139.598Max. pressure drop         (MPa)cont.141417.517.517.516.5131197int.16.517.52020202017.5151310peak22.522.522.522.522.522.522.52017.515Max. flow   (L/min)cont.40506060606060606060int.45607575757575757575Weight (kg)6.56.76.977.37.688.599.5



Technical data for BMR with 31.75 and 32 shaft:

TypeBMRBMRS36BMRBMRS50BMRBMRS80BMRBMRS100BMRBMRS125BMRBMRS160BMRBMRS200BMRBMRS250BMRBMRS315BMRBMRS375Geometric displacement (cm3 /rev.)3651.781.5102127.2157.2194.5253.3317.5381.4Max. speed  (rpm)cont.1250960750600475378310240190155int.15201150940750600475385300240190Max. torque  (N·m)cont.72100195240300380450540550580int.83126220280340430500610690690peak105165270320370460560710840830Max. output   (kW)cont.8.59.512.51312.512.5111097.5int.9.811.2151514.5141312109Max. pressure drop         (MPa)cont.141417.517.517.517.517.517.513.511.5int.16.517.520202020202017.515peak22.522.522.522.522.522.522.522.52117.5Max. flow   (L/min)cont.45506060606060606060int.55607575757575757575Weight (kg) 6.56.76.977.37.688.599.5

* Continuous pressure:Max.value of operating motor continuously.
* Intermittent pressure:Max.value of operating motor in 6 seconds per minute .
* Peak pressure:Max.value of operating motor in 0.6 second per minute.



Substitute Reference substance


MOTOR CROSS REFERENCE TABLE

HANJIU
HYDRAULIC

M+S
HYDRAULIC

EATON
CHAR LYNN

DANFOSS

ROSS
TRW

WHITE
CROSS

PARKER

SAM
BREVINI

BOSCH
RECROTH

BMM

MM   MLHK

J SERIES

OMM


BGM

MGX

BMP/BM1

MP    HP

H SERIES

OMP DH

MF MG

WP RS

TC TE TB

BG

MGP GXP

BMR/BM2

MR HR MLHRW,RW

S,T SERIES  W SERIES

OMR DS  OMEW

MB

WR RE

TF

BR

MGR GMR

BMH/BM4

MH MLHH HW HWF

OMH

ME

RE

TG

BMS/BM5

MS MSY MLHS

2000 SERIES

OMS

ME

RE

TG

HPR

MGS GMS

BMT/BM6

MT MLHT MTM

6000 SERIES

OMT TMT

MJ

HT

MGT,GMT

BMV

MV MLHV

10000 SERIES

OMV



MGV GMV



Hydraulic orbit motor applications:
Brush cutters
Mower
Haveresting equipment
Forestry equipment
Turf equipment
